Summary of Contents for Mangar Archimedes
- Page 1 Mangar Inc. 3020 Legacy Dr. Suit 100-301 Plano, TX 75023 tel: 1-800-901-5269 www.mangarusa.com Mangar International Presteigne Powys LD8 2UF Wales, UK ME0057 issue 3 tel: +44(0)1544 267674 fax: +44(0)1544 260287 (USA & Canada)
- Page 2 solutions...
-
Page 3: Table Of Contents
Be certain that it is CONTENTS positioned correctly before use. • Do not allow the Archimedes to lie on its back in the Standard Contents Pg 3 bath water. Getting Started Pg 3 •... -
Page 4: Standard Contents
Connect the hand control to the battery charger and plug the charger into a power supply OUTSIDE THE BATHROOM and allow the battery to charge overnight (see “Battery Charging”). Seat and base sections - The Archimedes can be easily separated into three sections (fig.2). • Seat section (A) •... -
Page 5: Fitting The Archimedes In The Bathtub
ME0057 issue 3 Fitting the Archimedes in the bathtub • Before placing the Archimedes in a bathtub, check that the surface where the suction cups will be sitting is clean and free from bath oil and cleaning residue. Remove anti-slip matting from this area. -
Page 6: Using The Archimedes
WARNING: In an emergency, the seat movement can be stopped at any time by disconnecting the hand control by pulling it away from the actuator lead (fig.9). NOTE: Releasing the ‘Up’ or ‘Down’ buttons at any time will also stop the seat movement. Removing the Archimedes from the bathtub • Fully lower the seat. • Fold the transfer flaps onto the seat. •... -
Page 7: Battery Charging
We recommend that the hand control is left continuously on charge when the Archimedes is not in use, as a matter of routine. Cleaning Regularly clean your Archimedes with the same non- abrasive cleaners that you normally use on your bathtub. -
Page 8: Maintenance
Other than routine cleaning, the Archimedes has been designed to be maintenance free, however, we recommend that your Archimedes is inspected annually by either your supplier or other suitably qualified person. Please contact your supplier for further advice. There are no user-serviceable parts in the Archimedes. Repairs or servicing must only be carried out by your supplier or other authorized person. Fault Finding If the seat fails to rise: •... -
Page 9: Parts List
ME0057 issue 3 Parts List Seat Assembly LA0010 Actuator Latch LA0016 Flap LA0011 Transit Tie LA0017 Hinge (Set of 2) LA0012 Hand Control LA0018 Base Assembly LA0013 10 Battery Charger LA0019 Suction Cup (Set of 4) LA0014 11 Flap Guards (pair - with instructions) -
Page 10: Symbols Used On Labels And Instructions
ME0057 issue 3 Symbols used on labels and instructions Maximum user weight limit Attention Press to raise seat Consult instructions Press to lower seat Alternating Current Direct Current Date of manufacture Class II Double Insulated Equipment Recycle do not dispose of in household... -
Page 11: Warranty
ME0057 issue 3 Warranty Mangar International guarantees this product for a period of two years. The guarantee is given against defects in material and workmanship and comprises piece, parts and labor. The guarantee is not valid in the case of fair wear and tear, wilful damage, common neglect, misuse or unauthorized alteration or repair by unqualified persons. - Page 12 ME0057 issue 3 freedom through lightweight solutions...
