PMT AS7.U101.100 User Manual

Universal laptop cradle
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
Description
UNIVERSAL LAPTOP CRADLE
UNIVERSAL LAPTOP CRADLE WITH 1" LONGER SIDE CLAMPS
UNIVERSAL LAPTOP CRADLE FOR THIN WIDESCREEN
UNIVERSAL LAPTOP CRADLE PRE CONFIGURED FOR
DURABOOK S14 LAPTOP (NO ADJUSTMENTS REQUIRED)
Universal Laptop Cradle
User Guide
www.precisionmounts.com
Part Number
AS7.U101.100
AS7.U101.101
AS7.U101.102
AS7.U101.104

Advertisement

loading
Need help?

Need help?

Do you have a question about the AS7.U101.100 and is the answer not in the manual?

Questions and answers

Summary of Contents for PMT AS7.U101.100

  • Page 1 Universal Laptop Cradle User Guide Description Part Number UNIVERSAL LAPTOP CRADLE AS7.U101.100 UNIVERSAL LAPTOP CRADLE WITH 1” LONGER SIDE CLAMPS AS7.U101.101 UNIVERSAL LAPTOP CRADLE FOR THIN WIDESCREEN AS7.U101.102 UNIVERSAL LAPTOP CRADLE PRE CONFIGURED FOR AS7.U101.104 DURABOOK S14 LAPTOP (NO ADJUSTMENTS REQUIRED)

  • Page 2: Top View

    Description of Parts and Layout Top View Hold Down Clamps (2) Side Clamps (4) Depth Adjustment Bracket Lock Release Handle Adjusting nuts (12)

  • Page 3: Bottom View

    Description of Parts and Layout Bottom View Mounting/Interface Plate Depth Adjustment Bracket Nuts (2)
  • Page 4 Adjusting Cradle for First Use/Fitment Step 1: Unlock cradle by turning key horizontal, then open cradle by squeezing the release handle towards the lock Step 2: Using a 3/8” wrench, loosen the nuts on the side and hold down clamps so they can move freely Step 3: With the cradle turned upside down,...
  • Page 5 Adjusting Cradle for First Use/Fitment Continued Step 4: Position the laptop so it is centered on the cradle, then slide it forward towards the front of the cradle resting on the front side clamps Step 5: With the screen of the laptop open, slide the release handle to the right (away from lock) which will close the side hold down clamps against the laptop.
  • Page 6 Adjusting Cradle for First Use/Fitment Continued Step 7: Position the back side clamps so that they do not interfere with any necessary ports or buttons, and so they are as far apart as possible. Ensure that the tops of the clamps do not interfere with the laptop screen when open, then tighten the nuts Step 8:...
  • Page 7 “Depth Fit Kit” to increase the min and max depth range the cradle will accommodate by 1 ¾”. Fit Kits are available from PMT at an extra cost. Part# AS7.U101.002-1 Remove existing bracket from cradle by removing the 2, 3/8” nuts then replace with the deeper bracket from the fit kit.
  • Page 8 Using the Universal Laptop Cradle Locking: With the cradle now adjusted and all nuts tightened completely, the laptop can be fully secured by locking the cradle (key vertical), removing the key, then sliding the release handle away from the lock Unlocking: To remove the laptop simply unlock the cradle with the key (key horizontal), then...
  • Page 9 PMT. Wiring Tip: PMT does not recommend relying on a cigarette socket adaptor for powering vehicle cradles. We recommend hard wiring using a good clean ground direct from the vehicle battery (-) post, and (+) supply from a fused 12v location also directly from the vehicle battery.

This manual is also suitable for:

As7.u101.101As7.u101.102As7.u101.104
