ALLTRONIC Micro7 Manual

Gate-Opener Control Type Micro 7 Threephase 400V
P1 WORKING TIME TRIMMER
P2 PAUSE TIME TRIMMER
P3 PEDESTRIAN TIME TRIMMER
F1 FUSE 5X20 T0,8A
F2 FUSE 5X20 F2A
RL1 LIGHT OF COURTESY RELAY (exit 24Vdc)
RL2 BLINKER RELAY OF 24Vac
RL3 OPEN RELAY
RL4 CLOSE RELAY
RL5 SECURITY RELAY and BLINKER RELAY 230V
DECLARATION OF CONFORMITY (according to ISO/IEC Guide 22 and EN 45014)
Manufacturer's Name :
Manufacturer's Address :
Product Name : Gate Opener for Rapid Door
Model : Micro7
CONFORMS TO THE FOLLOWING EMC SPECIFICATIONS BASED ON SAMPLE TESTING:
The product has been tested in the typical installation configuration and with peripherals which conform to EMC Directive.
I the undersigned declare that the product herewith complies with the protection requirements of the EMC Directive 89/336/
EEC, the 73/23/CEE Low Tension Directive and also the Directive 89/392/CEE (Electric Equipment Security of the Devi-
ces).
Bene Vagienna, 30/10/2006
For rolling (fast) door
TRIMMER – FUSE – RELAY
on 18Vac protection : electronic supply and exit 24Vdc.
on 230Vac protection : transformer, contacts and blinker of 230Vca.
ALLTRONIC s.n.c.
Via Torino. 84—12041 Bene Vagienna (Cn) Italy
DECLARES THAT THE FOLLOWING PRODUCT
EN 55011
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
EN 60335-1
EN 60204-1
EN 12453
EN 61000-6-1
EN 61000-6-3 + A11
Allodi Francesco
Proprietario
