3.4 Connecting LFP Connect to Power Conversion Electronics

Instructions on networking with specific power electronics are found in the relevant LFP Connect Card Manual. Refer also
to the specific power electronics guides for system configuration information.
HAZARD OF EQUIPMENT DAMAGE
• Do not plug an AEbus RJ-45 cable terminator into the 10/100 Ethernet port of the

LFP Connect.

• Do not connect a CAT5 cable from the 10/100 Ethernet port of the LFP Connect
to the WAN or MODEM port of a network router.
• Turn OFF all devices before connecting cables or inserting an LFP Connect Card.
Failure to follow these instructions will damage equipment.

4.0 OPERATION

4.1 Turning Power to LFP Connect ON and OFF
To power up LFP Connect gateway, switch the Rolls LFP battery to ON. To turn off power to LFP Connect gateway
switch the Rolls LFP battery to OFF.

4.3 Power Cycling LFP Connect

Use a pin to press and briefly hold the reset button on the front face of LFP Connect gateway.

4.4 Firmware Update

Refer to the Rolls Battery website (www.rollsbattery.com) for the latest firmware. If an firmware update is
require, ensure this is done by a qualified installer.

5.0 TROUBLESHOOTING

Symptom
Description
Action
CAUTION
NOTE
Power electronics are not AEbus devices and should
not be connected directly to AEbus.
AEbus LED is not on and SOC LEDs are scrolling
Power is detected but there are no AEbus devices
communicating
Check all cables and connection and that other
AEbus Devices are powered. Confirm that the network
is properly terminated (Note that the DC-DC
Power Conversion device and LFP Connect gateway
unit are internally terminated).
