Uniflame GBC900W-C Owner's Manual
Uniflame GBC900W-C Owner's Manual

Uniflame GBC900W-C Owner's Manual

Outdoor lp gas barbecue grill
Hide thumbs Also See for GBC900W-C:

Advertisement

Quick Links

Outdoor LP Gas Barbecue Grill
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
WARNING
FOR YOUR SAFETY:
1. Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly before
installing or servicing this equipment.
3. Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury, or death.
Save these instructions for future reference.
If you are assembling this unit for someone else,
give this manual to him or her to read and save
for future reference.
Made from 70% Bagasse
(Environmentally Friendly Sugar
Cane Pulp By-product)
OWNER'S MANUAL
Model No. GBC900W-C

Table of Contents

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2
Exploded View & Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installling LP Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Insert LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Secure LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connect LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Checking for Leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating Main Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
The use and installation of this product must conform to local codes. In absence
of local codes, use the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas
and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code,
B149.2.
Manufactured in China for:
Blue Rhino Global Sourcing, Inc
Winston-Salem, NC USA
1.800.762.1142, www.bluerhino.com
© 2008 Blue Rhino Global Sourcing, Inc. All Rights Reserved
UniFlame
is a Registered Trademark of Blue Rhino Global Sourcing, Inc.. All Rights Reserved.
®
GBC900W-C-OM-105 EF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GBC900W-C and is the answer not in the manual?

Questions and answers

Summary of Contents for Uniflame GBC900W-C

  • Page 1: Table Of Contents

    Manufactured in China for: Blue Rhino Global Sourcing, Inc Winston-Salem, NC USA 1.800.762.1142, www.bluerhino.com © 2008 Blue Rhino Global Sourcing, Inc. All Rights Reserved UniFlame is a Registered Trademark of Blue Rhino Global Sourcing, Inc.. All Rights Reserved. ® GBC900W-C-OM-105 EF...
  • Page 2: Important Safeguards

    Use only the regulator and hose assembly provided. The replacement regulator and hose assembly shall be that specified by the manufacturer. Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The use of any part that is not factory authorized can be dangerous. This will also void your warranty.
  • Page 3: Parts List

    Contact 1.800.762.1142 for assistance. Do not return to place of purchase. Parts List Exploded View Lid Handle 55-09-308 Warming Rack 55-09-321 Lid* 55-09-307 Cooking Grid 55-09-300 Heat Plate 55-09-303 Top Hinge (2)* 55-07-360 Bottom Hinge (2)* 55-07-306 Left Side Shelf 55-09-305 Heat Plate Support (2) 55-09-445...
  • Page 4: Assembly Instructions

    (4-5 gallon size) Note: You must follow all steps to properly assemble the grill. Typical assembly: approximately 1 (one) hour. Assemble Right Cart Frame Outdoor LP Gas Barbecue Grill Model No. GBC900W-C Assemble Left Cart Frame Attach Axle, Wheels and Hub Caps...
  • Page 5 Contact 1.800.762.1142 for assistance. Do not return to place of purchase. Attach Front Panels and Rear Panel x 12 Attach LP Gas Tank Retainer Wire Attach Cart Frame Support Wires Attach Lid Handle and Heat Plate Supports page no.
  • Page 6 Assembly Instructions (continued) Secure Grill Body Assembly Attach Side Shelf Supports Outdoor LP Gas Barbecue Grill Model No. GBC900W-C Attach LP Gas Tank Heat Plates Attach Side Shelves...
  • Page 7 Contact 1.800.762.1142 for assistance. Do not return to place of purchase. Attach Condiment Holder and Control Knobs Insert Warming Rack Insert Heat Plate and Cooking Grid Attach Grease Cup and Grease Cup Support page no.
  • Page 8: Installling Lp Gas Tank

    You can purchase a new full tank or exchange your empty for a precision filled one. Outdoor LP Gas Barbecue Grill Model No. GBC900W-C Operating Instructions Checking for Leaks Burner Connections 1.
  • Page 9: Cleaning And Care

    Contact 1.800.762.1142 for assistance. Do not return to place of purchase. Caution: If burner flame goes out during operation, immediately turn the gas “OFF” and open lid to let the gas clear for about 5 minutes before re-lighting. Turning Off 1.
  • Page 10: Product Registration

    1.800.762.1142. Limited Warranty Blue Rhino Global Sourcing, Inc (“Vendor”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in such product shall be free from defects in material and workmanship.
  • Page 11: Troubleshooting

    Contact 1.800.762.1142 for assistance. Do not return to place of purchase. Troubleshooting Problem Burner will not light using ignitor Burner will not light with match Sudden drop in gas flow or reduced flame height Irregular flame pattern, flame does not run the full length of burner.
  • Page 12 Outdoor LP Gas Barbecue Grill Model No. GBC900W-C...
  • Page 13 GBC900W-C nº modèle propane, d’extérieur Barbecue...
  • Page 14: Dépannage

    immédiate. assistance pour couvercle. rigoureusement Nettoyez carbone transformée s’est cuite graisse L’accumulation brûleur. tubes et/ou brûleur pièces. toutes retirez refroidi, barbecue Après consumer. laissez fermé couvercle Laissez (Fermé). » CLOSED propane bouteille robinet tournant Fermez (Arrêt). » « commande boutons température.
  • Page 15 GBC900W-C nº modèle propane, d’extérieur responsabilité n’engage représentations dépose l’utilisation, l’installation, s’attribuer société à personne tous. à applicables être peuvent limitations accessoires consécutifs dommages juridictions Certaines localité. selon reconnus l’acheteur à spécifiques responsabilité toute décline implicite plus, CONSÉCUTIFS. PUNITIFS INDIRECTS,...
  • Page 16: Entretien Et Nettoyage

    ondulantes. jaunes Flammes nettoyé: être doit brûleur risque ceci nécessaire. insectes venturi pour ci-dessous foncées. bleues flammes barbecue avec Bruyant nettoyé flammes d’être besoin brûleur propres sont ventilation ventilation. d’air hauteur. liquides entre jaunes crêtes avec claires matières bleues Flammes normal: État barbecue...
  • Page 17 Brûleurs respectez venturi Tube vérifiez l’orifice. tube venturi vérifiez brûleur régulateur propane orifice Raccord avec propane Soupape potentielle Illustration GBC900W-C nº modèle propane, à Reportez-vous (Arrêt). » « commande boutons Tous votre l’appareil. dessous vente provoquer risque ceci bouchée,...
  • Page 18 graisse support graisse collecteur cuisson grille chaleur vente. point page collecteur godet godet Fixez diffuseur Placez retourner 1.800.762.1142. réchauffage grille commandes boutons porte-condiments appeler assistance, toute Pour Placez Fixez...
  • Page 19 GBC900W-C nº modèle propane, Fixez bouteille Fixez d’extérieur Barbecue latérales tablettes supports Fixez barbecue cuve Fixez (suite) d’assemblage Instructions...
  • Page 20 chaleur supports couvercle chariot support vente. point page diffuseur poignée Fixez propane tiges Fixez retourner 1.800.762.1142. bouteille retenue l’étrier arrière panneau avant panneaux appeler assistance, toute Pour Fixez Fixez...
  • Page 21 Assemblez GBC900W-C nº modèle propane, d’extérieur Fixez chariot heure. afin l’ordre dans étapes externe filetage à robinet litres) à barbecue »). Fonctionnement « instructions suivantes: choses besoin d’assembler afin complètement. serrez-les terminée, visserie fixations d’installation.
  • Page 22 (fournis) l’assemblage vente. point page Clé nº Phillips cruciforme Tournevis pour requis Outils 55-09-323 55-09-322 55-09-304 55-09-311 55-09-296 55-09-310 gauche retourner 1.800.762.1142. ø6.4 Nickelée, ø6,4 chaleur, à Résistante ø6.4 Nickelée, oreilles Acier, Galvanisé, Galvanisé, M6x14 Phillips, bombée tête à Nickelée, ST4,8x10 Phillips, bombée...
  • Page 23 SÉCURITÉ: VOTRE POUR AVERTISSEMENT GBC900W-C nº modèle propane, blessures d’entraîner aéré. bien consignes respect ci-dessus consignes à d’ignition d’aluminium. recouvrir jamais bouteille d’endommager éviter “test...
  • Page 24 GBC900W-C-OM-105 réservés. droits Tous Inc. B149.2. propane, CAN/CGA-B149.1 propane, naturel ANSI normes combustible, locaux. codes conformes être Page propane D’UTILISATION Sourcing, Global Rhino Blue déposée marque UniFlame ® réservés. droits Tous Inc. Sourcing, Global Rhino Blue 2008 www.bluerhino.com 1.800.762.1142, États-Unis...
