Gas Log Splitter
Operator's Manual
MODEL NUMBER
□
YU2566
□
YU2866
□
YU3066
□
YU3566
SERIAL NUMBER
I
PURCHASE DATE
I
Both model number and serial
number may be found on the
main label. You should record
both of them in a safe place for
future use.
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE
I
I
FOR YOUR SAFETY
Save This Manual for Future Reference
Tame the Great Outdoors·
7
Advertisement
Table of Contents
Related Manuals for YARDMAX YU2566
Summary of Contents for YARDMAX YU2566
- Page 1 Save This Manual for Future Reference Gas Log Splitter Operator's Manual MODEL NUMBER □ YU2566 □ YU2866 □ YU3066 □ YU3566 SERIAL NUMBER PURCHASE DATE Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use.
-
Page 2: Table Of Contents
When looking for outdoor power equipment (OPE) to get the job done right, at the right price, YARD MAX delivers the perfect combination of performance and practicality. YARDMAX has a solution that's right for you. TABLE OF CONTENTS Introduction Know Your Machine... - Page 3 California to cause cancer and birth defects DISCLAIMER or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. YARDMAX reserves the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and ENVIRONMENTAL specifications contained in this manual were in effect at printing.
-
Page 4: Specifications
SUPPORT Have questions about your YARD MAX equipment? Call us at 847-327-0566 or 844-YARDMAX, email us at support@yardmax.com, or contact us via your favorite social media site. SPECIF I CATI ON S Model# YU2566 YU2866 YU3066 YU3566 Splitting Force* 25ton... - Page 5 Gas Log Splitter » Operator's Manual Model# YU2566 YU2866 YU3066 YU3566 Pump Size 14GPM 14GPM 17GPM 17GPM Hydraulic Cylinder Bore 4" 4.5" 4.5" 5" 24 " 24 " 24 " 24 " Hydraulic Cylinder Stroke 1.75 " 2 " Hydraulic Rod Diameter 1.75"...
-
Page 6: Symbols
SYMBOLS The rating plate on your machine may show symbols. These represent important information about the product or instructions on its use. Never remove partially split wood from Read these instructions carefully. the wedge with your hands. Fingers may become trapped between the split wood. �... -
Page 7: Safety
Gas Log Splitter » Operator's Manual SAFETY GENERAL SAFETY RULES Wear appropriate hearing protection. UNDERSTAND YOUR MACHINE Read this manual and labels affixed to the machine to understand Always keep hands and feet away from all moving parts during its limitations and potential hazards. operation. - Page 8 ENGINE SAFETY Avoid creating a source of ignition for spilled fuel. If fuel is spilled, do not attempt to start the engine but move the machine away This machine is equipped with an internal combustion engine. from the area of spillage and avoid creating any source of ignition Do not use on or near any unimproved, forest covered, or brush until fuel vapors have dissipated.
- Page 9 SPECIFIC SAFETY RULES VERTICAL OPERATING POSITION PREPARATION OF T HE LOG Both ends of the log should be cut as square as possible to prevent the log from rotating out of the splitter during operation. Never split logs greater than the specified log capacity. Do not operate the log splitter on icy, wet, muddy, or slippery ground.
- Page 10 TOWING SAFETY Never allow anyone to ride or sit on the log splitter. Check all local and state regulations regarding towing, licensing, Always stop the engine, lock the beam in the horizontal position, and lights before towing your log splitter. and close the fuel shut-off valve when transporting the unit.
-
Page 11: Unpacking The Container
Gas Log Splitter » Operator's Manual UNPACKING THE CONTAINER Use the screwdriver and hammer to open all the side locks. Remove all the polywood plates. Remove all the loose parts on the bottom Figure 1a) pallets. Use scissors or a knife to cut all the straps. (See -���... -
Page 12: Contents Supplied
{()@ Manual Tube �I Bridge Pin 1:11 10. Operator's Manual and Engine Manual ■-- (p@@ M10X25 11. Tools for Spark plug Assembly (YU2566 and YU2866 only) M8X20 ■ 12. Engine Oil 13. Log Table (Optional) �@@@ M12X35 1:111 OPTIONAL 1111... -
Page 13: Assembly
Gas Log Splitter Operator's Manual » ASSEMBLY This log splitter was partially assembled at the factory. To assemble your machine follow the below instructions. WHEELS Assistant holds the engine, while the other person assembles the wheel opposite of the engine first. At least two people are needed to move the reservoir outside of the pallet. - Page 14 Insert the cotter pin through the hole in the axle. Bend open After the beam and cylinder assembly is in the and spread the prongs in opposite directions so the axle nut vertical position, a helper is needed to prevent will not come off (make sure the tire spins freely).
- Page 15 Align the pivot bracket on the beam assembly to the pivot PIVOT BRACKET mount on the tank weldment and insert the beam pivot pin Align the holes in the pivot bracket with the holes on the beam and washer. (See fisure 7b) and insert and tighten bolts, spring washers, and flat washers.
- Page 16 Figure Hold the lifting handle and slowly lower the beam. It will lock 2. Follow step 1 to assemble the left log cradle. (See automatically. Double check to make sure the beam bracket is locked onto the beam. Do not let the beam suddenly drop. Keep hands and �...
-
Page 17: Know Your Machine
Gas Log Splitter » Operator's Manual KNOW YOUR MACHINE FEATURES AND CONTROLS log Table (Optional) Log Spinner Foot Plate 2-Position log Cradle G¥iWD·M I@ Mi I: ttfl k Qj@H§ I Mftffl; ttfl M ttffl@ :f&WtttMrttl@I ii - 44iij0tffl l$M,\ Miiti·I· Beam Lock Bracket Beam Assembly Support'Leg... - Page 18 ©! Mtffitltl-tltNllttm► JqQ, ---Ecc::::_,. I®' U ttirtfl ffii #lfiffll#•Utki0- LOG SPINNER FOOT PLATE LIFTING HANDLE The foot plate holds the log in place while the wedge The lifting handle is included for easy transition from splits the log. horizontal to vertical. The foot plate allows the operator to easily spin a log 2•...
-
Page 19: Operation
Gas Log Splitter » Operator's Manual THROTTLE CONTROL FUEL SHUT-OFF VALVE The throttle control regulates the speed of the engine The fuel shut - off has two position. CLOSED (S)) and will shut off the engine when it is moved to the - use this position to service, transport, or store the STOP position. - Page 20 STARTING ENGINE STOP ENGINE 1. Make sure the control lever is in the neutral position. Return the cylinder to fully retracted position or home position. Move the Throttle lever to SLOW (-A). Move the engine switch to OFF. Close the fuel shut-off valve (Ii)). Sudden stopping at a high speed under a heavy load not recommended.
- Page 21 Gas Log Splitter » Operator's Manual CONVERSION BETWEEN HORIZONTAL SPLITTING Neutral Position POSITION AND VERTICAL SPLITTING POSITION Forward Horizontal Beam Lock ■ :fffl@·l,i M IMM, Figure 12a Lifting Handle Reverse Position Neutral Position Forward Position Figure 12b STUCK LOG PROCEDURE If a log does not split completely and becomes stuck on the wedge, never attempt to remove it by modifying the splitter or adding attachments to the splitter.
-
Page 22: Transporting
TRANSPORTING MOVING BY HANDS order. 3. Make sure hitch is in good working 4. Check safety chains. Two safety chains must be used while T he log splitter heavy. It can crush and cause � Cross towing. safety chains under the coupler, allowing only serious injury if it rolls out of control or tips over. -
Page 23: Maintenance
Gas Log Splitter » Operator's Manual MAINTENANCE Inspect and maintain the log splitter before each use. If the ADD HYDRAULIC OIL TO OIL TANK log splitter has been used previously, it must be inspected and 1. Make sure the log splitter is on a flat, level surface. maintained before each subsequent use. -
Page 24: Storage
STORAGE Follow the instructions below for storing your log splitter between Always drain fuel from the tank in an outdoor, well uses. ventilated area. 1. Retract the wedge completely to keep the rod protected from Stay away from sources of heat, flame, or sparks corrosion. -
Page 25: Troubleshooting
Gas Log Splitter » Operator's Manual TROUBLESHOOTING Problem Cause Remedy Purge air by extending and retracting the Air in the hydraulic oil system wedge several times until motion is smooth Debris lodged in beam guides Wedge movement is Clear debris from beam slow or erratic Low hydraulic oil Check oil level and add as needed... -
Page 26: Parts Diagram
..YU2566/YU2866 67 26 � � �� l 1 n r _ ..n "'\. � _ \ 12 [i 1 ,_ , c-0.--.. -d .--.. -- d - , � .._,. - - ! ; o=o--@-' - --��{ �... - Page 27 Gas Log Splitter » Operator's Manual YU2566/YU2866 PARTS LIST Description Q ty Description Q ty Description Pin 35x59 Pin6x40 73 Dust Cap Bridge Pin Discontinued A x leNutM22 Hose Clamp 40 NutM10 Tank Assembly Hex Socket Head Cap Screw M6x20 1...
- Page 28 YU3066 • Parts List on page 30 r-..
- Page 29 Gas Log Splitter » Operator's Manual YU3066 PARTS LIST Description Q t y Description Q t y Description Q t y Pin 35x59 Pin6x40 A x leNutM22 Bridge Pin 38 Discontinued Tank Assembly Hose Clamp 40 NutM10 Washer20 Hex Socket Head Cap Screw M6x20 1 Spring Washer 8 Drain Plug Right-Angle Fitting...
- Page 30 YU3566 � \ LA�� ���� � - �-- - - - - • • Parts List on page 30 �-T� - - _ , ��� � �1� fl fl 3 0 29 - 1 �� � - - _ _ _ _ __ -l(i _ _ _ _ _ ----=---.1...
- Page 31 Gas Log Splitter » Operator's Manual YU3566 PARTS LIST Description Q ty Description Q ty Description Q ty Pin 35x59 Spring Washer 8 79 -1 Clamp 25 -38 Bridge Pin Bolt M8x20 80 -1 Suction Hose Hose Clamp 40 Washer8 Return Oil Filter Hex Socket Head Cap Screw M6x20 Bolt M12x90...
