CONSTRUCTION MANUAL

AND OPERATING INSTRUCTIONS

Table of Contents

Need help?

Do you have a question about the RobCo Pip-Boy Stand and is the answer not in the manual?

Questions and answers

Summary of Contents for The Wand Company RobCo Pip-Boy Stand

Page 1 CONSTRUCTION MANUAL AND OPERATING INSTRUCTIONS...
Page 2 INTRODUCTION The Pip-Boy Stand Bluetooth speakerphone when paired with a suitable mobile phone. Speaker Kit is a faithful replica Impress camp mates with your speaker building skills and Acoustic Wadding Bass Re ex Port of the Pip-Boy stand created by RobCo for Vault-Tec that discover its 10 authentic Overseer comments, each BOX 3 BOX 4...
Page 3 M5 Nut BOX 3 1:1 COMPONENT GUIDE 1:1 COMPONENT GUIDE Upper Main Housing M5 Nut BOX 3 BOX 3 Push two of the M5 Nuts into the upper hexagonal recesses in Bass Re ex Port front face. Push two of the M5 Nuts into the lower hexagonal recesses in the Bass Re ex Port front face.
Page 4 Medium M4 Spacer Nut Back Stand Support Cover BOX 3 BOX 2 Insert two Medium M4 Small O-Ring Spacer Nuts into their slots each side of the BOX 3 Front Stand Support Cover, so that they push into position, taking care that they 1:1 COMPONENT GUIDE locate properly and don’...
Page 5 IMPORTANT : When screwing the top and bottom parts of the Base together, two different types of screw are used. There Rotate Back Stand Support Cover into are two M5 Machine Screws and two 12 mm Thread-forming Screws. They appear to be very similar, but look carefully at position so that it ts squarely onto the the screws and note the difference.
Page 6 Clear Rubber Foot BOX 3 Screw the two M5 Machine Screws into the captive nuts at the Support Stand end of M5 Machine Screw the Base underside. BOX 3 1:1 COMPONENT GUIDE Stick the four Clear Rubber Feet into position on the underside of the Base.
Page 7 Small Thread-forming Screw BOX 3 Place the two Front Pipe 1:1 COMPONENT Sections into position on GUIDE top of the Base and clip into place with the other Double Pipe Clip. Screw the Small Thread- forming Screw through Double Pipe Clip the underside of the Base BOX 3 to secure the Large Single...
Page 8 OPERATING INSTRUCTIONS Pip-Boy Display Stand Replica • Your music streaming device should report that it is pairing. • Once the Stand is paired it will emit a short high-pitched tone and say, “Connected”. • The Bottom Indicator will double ash blue while the Stand is connected.
