Blue Wave ACCELERATOR Assembly Instructions Manual

4in1 multi-game table
Hide thumbs

Advertisement

Quick Links

Download this manual
ACCELERATOR 4in1 MULTI-GAME
TABLE ASSEMBLY INSTRUCTIONS
NG1016M

Advertisement

loading
Need help?

Need help?

Do you have a question about the ACCELERATOR and is the answer not in the manual?

Questions and answers

Related Manuals for Blue Wave ACCELERATOR

Summary of Contents for Blue Wave ACCELERATOR

  • Page 1 ACCELERATOR 4in1 MULTI-GAME TABLE ASSEMBLY INSTRUCTIONS NG1016M...
  • Page 2 THANK YOU! Thank you for purchasing this product. We work around the clock and around the globe to ensure that our products maintain the highest possible quality. However, in the rare case of issues during assembly or use of this product, please contact our Consumer Hotline at 800-759-0977 for immediate assistance before contacting your retailer.
  • Page 3 PARTS IDENTIFIER (NOT TO SCALE) P1 NGP6000 P2 NGP6001 P3 NGP6002 P4 NGP6003 P5 NGP6004 TABLE TENNIS WHITE BOARD TABLE BODY LEG PANEL LEG LEVELER 1 pc 4 pcs 2 pcs 1 pc 4 pcs P10 NGP6009 P6 NGP6005 P7 NGP6006 P8 NGP6007 P9 NGP6008 BASKETBALL...

  • Page 4: Assembly Tips

    ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. The table will be partially assembled upside down and then turned over onto its legs. This is a heavy game and turning it over will require at least two strong adults. 2.
  • Page 5 THANK YOU! ASSEMBLY INSTRUCTIONS 1. Attach one LEG P2 to each corner of the TABLE BODY P1 using BOLTS P23 and WASHERS P22. 2. Attach LEG PANELS P3 to inside of LEGS P2 on each end of table using SCREWS P24 in pre-drilled holes. 3.
  • Page 6 ASSEMBLY INSTRUCTIONS (CONT.) 5. Attach two BASKETBALL ARMS P6 onto end of TABLE BODY P1 using BOLTS P23 and WASHERS P22. 6. Attach BACKBOARD P7 onto BASKETBALL ARMS P6 using four BOLTS P20 and NUTS P21 as shown.
  • Page 7 ASSEMBLY INSTRUCTIONS (CONT.) 7. Attach the BALL RETURN NET P10 to the two BASKETBALL ARMS P6 using the Velcro strips as shown. 6. Attach the black straps on the front sides of the BALL RETURN NET P10 to the sides of table using BOLTS P19 and WASHERS P22.
  • Page 8 ASSEMBLY INSTRUCTIONS (CONT.) Simply remove the basketball assembly to play AIR HOCKEY. Place the dry erase board on top of the table to create a DESK or ART/CRAFT AREA. Flip the dry erase board over, insert the net posts and net, and you’re ready for TABLE TENNIS.

  • Page 9: Care And Use

    CONGRATULATIONS! You have now assembled your Game Table. Please note the Care and Use instructions below to ensure years of trouble free use of your game table. CARE AND USE 1. This product is intended for INDOOR use only. 2. Do NOT sit, climb or lean on the table. 3.
  • Page 10 180-DAY LIMITED WARRANTY This product is warranted to the original purchaser to be free from defects in material or workmanship for a period of 180 days from the date of the original retail purchase. This warranty does not cover defects or damage due to improper installation, alteration, accident or any other event beyond the control of the manufacturer.
