RED LABEL RL750FAN Owner's Manual

Hide thumbs

Advertisement

Table of Contents

Oct-18
Product Code: RL750FAN
OWNER'S MANUAL
PRODUCT CODE: RL750FAN
PEDESTAL FAN
Blade
Motor
Adjustable Height
Oscillating Range
Fan Head Tilt
Diameter
Input Output
(Fan Centre)
°
750mm
240V 50Hz 280W
0º to 90º
1235 - 1760mm
15
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RL750FAN and is the answer not in the manual?

Questions and answers

Summary of Contents for RED LABEL RL750FAN

  • Page 1 Oct-18 Product Code: RL750FAN OWNER’S MANUAL PRODUCT CODE: RL750FAN PEDESTAL FAN Blade Motor Adjustable Height Oscillating Range Fan Head Tilt Diameter Input Output (Fan Centre) ° 750mm 240V 50Hz 280W 0º to 90º 1235 - 1760mm Made in China to TQB Brands Pty Ltd specifications...

  • Page 2: Table Of Contents

    Oct-18 Product Code: RL750FAN WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works.

  • Page 3: Safety Instructions

    Oct-18 Product Code: RL750FAN SAFETY INSTRUCTIONS SAFETY OPERATING INSTRUCTIONS This product is intended for indoor use only. Always operate the product from a power source of the same voltage, frequency and rating as indicated on the product identification plate. To reduce the risk of electric shock, do not use this fan with any solid-state speed control device.

  • Page 4: Assembly, Operation, Preventitive Maintenance

    Product Code: RL750FAN ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES This Red Label Workshop Fan is a great value for money pedestal fan which is ideal for cooling large open workshop areas 2. BEFORE USE Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked joins and damaged, loose, or missing parts.
  • Page 5 Oct-18 Product Code: RL750FAN Attach the front Safety Grill to the Fan Motor Align the top locking clip on the Front Grill (2) to the top centre of the Rear Grill (8) that has already been secured to the fan motor. Lock the side and bottom clips in place.
  • Page 6 - any other condition that may affect the Pedestal Fan safe operation 7. SERVICE & REPAIR Any Red Label Fan found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent.

  • Page 7: Parts List Stand Fan

    Oct-18 Product Code: RL750FAN PARTS LIST STAND FAN Part # Description Part # Description Centre Plate Bolt Front Grill Screw Fan Blade Flex Support Screw Fixing Cover Bolt Fixing Screw Spring Washer Locking Bolt Washer Support Column Rear Grill Separating Cover...

  • Page 8: Warranty

    Product Code: RL750FAN WARRANTY Red Label products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
