Instinct
Display Module Replacement
Kit Part Number
INSRKIT53
Each Kit Includes:
• Display Module with cover
Recommended Tools:
• Adjustable Wrenches
• Phillips Head Screwdriver
• Flat Head Screwdriver
WARNING
!
Indicates a potentially hazardous situation which,
if ignored, can result in serious injury or substan-
tial property damage.
WARNING
!
For your safety, turn off electrical power supply
at service panel and allow unit to cool before pro-
ceeding to avoid possible electrical shock and
scald hazard. Failure to do so can cause severe
personal injury or death.
2019-45 Instinct Display Module Replacement
Revised 10/23/2109
Description
Display Module Replacement
NOTICE
Indicates special instructions on installation, operation
or maintenance, which are important to equipment
but not related to personal injury hazards.
!
Failure to follow instructions below can result in
severe personal injury or damage if ignored.
•
•
•
Model
Instinct
WARNING
Instructions are for a qualified installer/ ser-
vice technician only.
Read all instructions before proceeding.
Follow instructions in proper order.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the INSRKIT53 and is the answer not in the manual?

Questions and answers

Summary of Contents for TriangleTube INSRKIT53

  • Page 1 Instinct Display Module Replacement Kit Part Number Description Model INSRKIT53 Display Module Replacement Instinct Each Kit Includes: • Display Module with cover Recommended Tools: • Adjustable Wrenches • Phillips Head Screwdriver • Flat Head Screwdriver NOTICE WARNING Indicates special instructions on installation, operation...

  • Page 2: Preliminary Instructions

    Instinct Display Module Replacement the OK button to enter the access code. 1. Preliminary Instructions 1. Verify that the replacement kit is correct for the model of boiler. See table on page 1. 2. Carefully open and unpack the PARTS BOX from its shipping carton.
  • Page 3 Instinct Display Module Replacement 6. Record all CH Settings in Table 1. Once completed, 12. Press the RIGHT then DOWN buttons to highlight press the RIGHT button to highlight the Previous the Cascade icon, then press the OK button. Screen icon, then press the OK button. 13.
  • Page 4 Instinct Display Module Replacement 7. Reconnect the yellow cables by pushing the plug 3. The required code is written on the data plate lo- into the terminal. The clip on the back of the plug cated at the side of the boiler. Use the code for the will lock the plug into place.
  • Page 5 Instinct Display Module Replacement Table 1: Controls Settings HEATING SETTING FACTORY DEFAULT MINIMUM SETTING MAXIMUM SETTING EXISTING SETTING Heating Operation Enabled Demand Type Thermostat & Outd. Curve Absolute Max CH Setpoint 185°F [85°C] 68°F [20°C] 188°F [87°C] CH1 Maximum Setpoint 180°F [82°C] 68°F [20°C] 188°F [87°C] CH1 Minimum Setpoint 80°F [27°C] 60°F [15°C]...
