Page 1: Table Of Contents
Video Glasses INDEX Main function Article No. 50546 Note Appearance and buttons Accessory Basic Operation Menu Video player Photo browser E-Book File Manager Record Camera mode Settings Games USB Using Charging Common problems and solutions Technical specifications...
Page 2: Article No. 50546
Main functions • Supports AV in function, can connect with any products with AV/TV out function,such as VCD, DVD, TV, MP4, PMP, VCR, video recorder, 3G-MOBILE, X-BOX, etc. • Supports RM, RMVB(High Definition:720P,resolution :1280*720,4MB codestream) AVI, FLV, MP4, MPEG, DAT, 3GP, WMV, VOB, ASF video format. •...
Page 3 note • If you do not use the video glasses, please turn the power button to ‘OFF” to save the lithium battery. • Please avoid fall, strong collision and heavy vibration, because the display can be corrupted and also image interference can occur. •...
Page 4: Appearance And Buttons
appearance and MultiMedia player button configuration: 1. Camera button 2. USB port 3. AV-IN 4. Function buttons 5. AV-OUT port 6. Earphone jack 7. Confirmation button 8. R eturn button 9. ON/OFF 10. Game Playing control buttons 11. SD card socket...
Page 5: Accessory
accessory Connection Devices Accessory...
Page 6: Basic Operation
Basic Operation oN / off SWITCH ON: First of all you need to connect the glasses to a multimedia player AV-OUT port. Switch the button to “ON” and a blue light appears. The video glasses enter the main menu. If you want to reopen the glasses, please wait for 3 seconds after switching off.
Page 7 power oN In the unlikely event of a system break down, please switch off, and then connect to the computer h the and File Transfer. open The USB cable can be connected to a computer to allow data transfer functions via the removable hard disk.
Page 8: Menu
MENU In the main menu interface, press ◀ ▶ to choose one of the seven available options: Video / Photo / E-book / File Manager / Camera / Setting / Game. Press confrimation button ◀ ▶ to enter the function menu. In the Setting, File management, etc.
Page 9: Photo Browser
irec- pHoto browser Press confirmation button ▶ to enter picture mode Short Press button ▲▼ in the index to select program, and then press ▶ to browse. Press button ◀ ▶ to select previous / next file. Press ▲ to zoom in and ▼ to zoom out, Press button ”B”...
Page 10: E-Book
E-Book Press confirmation button ▶ to enter e-book mode Presss button”B” in the index to choose “Delete”. Press ▲▼ in the index to select program, and then press ▶ to read. Press ▲▼ to choose previous / next page. Presss button” B” in the reading mode to enter the Sub-menu:” New bookmark” ,”Bookmark list”,”Return”. Then presss ▶...
Page 11: File Manager
file Manager You can’t delete any documents in the “File Manager”. You can only delete them in the corresponding menu. urn”.
Page 12: Record
record Mode Press confirmation button ▶ to enter record mode Press confirmation button ▶ to start recording, and press again to stop recording. Press ▶ to listen to the recording. Press to return to the previous directory. You can also check the recorded file in “ARECORD” in the “File Manager” menu.
Page 13: Camera Mode
caMera Mode Press confirmation button ▶ to enter camera mode Press camera key to start camera or press the confirmation button ▶ to start photographing. Please view pictures in the “photo” menu and press button “B” to enter submenu: ”Slide”, “Delete photo”, ”Photo information”, ”Exit menu”.
Page 14: Settings
settings Press confirmation button ▶ to enter setting mode. Press ▲▼ to select sub-menu: ”Language”, “TV setting”,”Memory” and “System default setting”. Press ▶ to enter the third stage menu. language setting: Press ▲▼ to choose the language then press to return. tV setting: Press ▲▼...
Page 15: Games
gaMes Press the confirmation button ▶ to enter game mode. Short Press ▲▼ button to select a game then press confirmation button to enter the selected game. Buttons ▲▼ ◀ ▶ are direction keys in the game mode. Press confirmation button ▶ to start or pause the game.
Page 16: Usb Using
usb using Switch the multimedia player “ON” before operation. The video glasses have a high-speed USB2. 0 interface, with standard removable disk function. The de- vice supports Windows98 (driver needs to be installed) and Windows2000/XP/Vista (no need to install driver). When connecting with a PC you have to wait a few seconds till the device is displayed as being on-line.
Page 17 c) Key doesn’t respond • Shutdown and then restart d) Noise • Check whether the headphone plug is clean. Dirt can cause noise • Check whether the file is corrupted. Try playing other files. Damaged files will cause e) Screen display is garbled •...
Page 18 h) The capacity of the removable disk decreases • Connect the player to the computer. Right click on “Removable Disk“ and select Format. The For- mat dialog box appears. Select FAT32 from the file system options, click the Start button, and then follow the prompts to complete the operation.
Page 19: Technical Specifications
tecHnical specifications MULTIMEDIA PLAYER CONNECTION TO COMPUTER High speed USB 2.0 (FS) flash disk MEMORY Flash memory: 128MB–8GB, external SD card :1GB–8GB LITHIUM BATTERY Max video playback time 3 hours,1000mAh replaceable Lithium battery VIDEO FORMAT RM / RMVB (High Definition:720P, resolution: 1280*720, 4MB codestream) PHOTO FORMAT JPG, BMP, GIF CAMERA...
Page 20 tecHnical specifications VIDEO GLASSES MONITOR DISPLAY SIZE QVGA 40寸(distance 2M) RESOLUTION 320*240(QVGA) VIEWING ANGLE 35 degrees VIDEO FORMAT NTSC/PAL/SECAM AUDIO OUTPUT Stereo earphone 0.1 W × 2 channels AC ADAPTER Input 100-240Vac, 50-60HZ,output 5V, 500mA OPERATION TEMPERATURE -10°C – 60°C AUDIO / VIDEO SPECIAL PORT Special interface Can be connected to any devices with AV/TV-OUT function and...
Page 21 battery disposal instructions In connection with the sale of batteries or with the supply of products wich have batteries included, the dealer is obliged to advise you of the following: • As an end user, you are obligated by law to return used batteries. •...
Page 22 Distributor: Segula GmbH, 50667 Köln www.segula.de...
