- Page 1 DVS Filtertechniek Aan de Fremme 53 B 6269BK Margraten www.dvs-filtertechniek.com info@dvs-filtertechniek.com QUICK GUIDE v1.4 DVS FILTERSYSTEMS...
-
Page 2: Table Of Contents
QUICKGUIDE Index BASIC REQUIREMENTS ....................3 1.1 Control unit ......................4 A. GRAVITY-SYSTEM ....................5 2.1 Placing the filter system ..................5 2.2 Set level control: ..................... 8 B. PUMP FED SYSTEM ....................9 3.1 Placing filter system ....................9 3.2 Set level control: .................... -
Page 3: Basic Requirements
QUICKGUIDE 1 Basic requirements Basic requirements every filter system must meet: The filter system should be placed on a ground surface with sufficient carrying capacity, for instance: − a well-vibrated sand bed of 10 cm, possibly with concrete tiles −... -
Page 4: Control Unit
QUICKGUIDE 1.1 Control unit Power Switch Manual Cleaning Plug Plug Sensor Motor Drumfilter Plug Plug Cleaning Pump Circulation Pump... -
Page 5: Gravity-System
The filter should be placed the height of the installation height (fig. 2.1) above water level. (installation height is the distance from maximum water level to top of filter). Type filter Installation height [cm] ECO15 ECO22 PP22 PP35 PP50... - Page 6 QUICKGUIDE GRAVITY Schematic setup of the drum filter Pic. 2.1 1. Water level with running pump after rinse (short pen 8 cm in water) 2. Start rinsing 3. Pond pump switches off 4. Installation height PP is 17 cm...
- Page 7 QUICKGUIDE GRAVITY Schematic setup of the combi drum filter Pic. 2.2 1. Water level with running pump after rinse (short pen 8 cm in water) 2. Start rinsing 3. Pond pump switches off 4. Installation height CL is 14 cm...
-
Page 8: Set Level Control
1. Water level with running pump after rinse (short pen 8 cm in water) 2. Start rinsing 2. Start rinsing 3. Pondpump switches off For more detailed information you are referred to the complete manual. This can be found at www.dvs-filtertechniek.com... -
Page 9: Pump Fed System
QUICKGUIDE PUMP FED 3 B. Pump fed system Placing filter system Determine the maximum water level of the pond Align the base plate horizontally (the filter should be completely level). The drumfilter must be placed 30cm higher than the biochamber. (the distance from top of the drumfilter, to the top of the biochamber is 30cm) Schematic setup of the drum filter Pic. - Page 10 QUICKGUIDE PUMP FED Schematic setup of the combi drum filter Pic. 3.2 1. Water level with running pump after rinse 2. Start rinsing 3. Pond pump switches off...
-
Page 11: Set Level Control
1. Water level with running pump after rinse 1. Water level with running pump after rinse 2. Start rinsing 2. Start rinsing 3. Pond pump switches off For more detailed information you are referred to the complete manual. This can be found at www.dvs-filtertechniek.com... -
Page 12: Water Valve ( Plc)
QUICKGUIDE 4 Water Valve ( PLC) Automatic refill Pond Waste cleaning...
