Summary of Contents for WATERLOO Smart Panel
- Page 1 Smart Panel Owner’s Manual Waterloo Biofilter Systems Inc. 143 Dennis Street, PO Box 400 Rockwood ON N0B 2K0 Tel: 519-856-0757 Fax: 519-856-0759 1-866-366-4329 info@waterloo-biofilter.com www.waterloo-biofilter.com © Waterloo Biofilter Systems 2019...
- Page 2 Table of Contents Table of Contents ............................2 Alarms ................................. 3 Main Display ............................... 4 Customer Menu ............................5 How to Perform Function Test ....................... 6 How to use Manual Mode ........................7 Check Active Inputs ..........................8 Page | 2 Owner’s Manual...
- Page 3 Remember that this does NOT mean the problem has been solved, you will still need to contact Waterloo Biofilter or your service provider to rectify the situation. Page | 3 Owner’s Manual...
- Page 4 Main Display 1. Outputs Displays active and Inactive. In the picture above Outputs 1 is Active (shaded) and Output 2 is inactive. Depending on the number of outputs connected to the panel, the display will change. When an output is active, the timer counts down how long until it is deactivated. When the output is inactive, the timer counts down how long until it is activated.
- Page 5 Customer Menu The Customer Menu gives access to the basic functions of the control panel. This section is accessed by pressing the Down arrow on the main screen. Device Information General information regarding the device. Includes Firmware version, Serial Number, Variant information and production date.
- Page 6 How to Perform Function Test Function Test allows a user to perform a quick run through all the outputs to verify proper operation and amperage readings. The cycle will run through all enabled outputs by sequence, test the alarm and check the backup battery status. Once the user has accessed the Customer Menu, scroll Down to Function Test and Press OK...
- Page 7 How to use Manual Mode Manual Mode allows operator(s) to temporarily run a specified output for a period of time. The time of this run is predetermined at time of construction. Once the user has accessed the Customer Menu, scroll Down to Manual Mode and Press OK In the Manual Mode menu scroll down to the Output you would like to control, Press OK...
- Page 8 Check Active Inputs Active Inputs can be check on the Main Screen of the panel. Near the bottom of the screen Inputs display whether Inputs 1 to 4 are active. Shaded Inputs are active. If there are more than 4 inputs in the control Panel the input screen needs to be accessed to verify the status of the remaining inputs.
