mikroElektronika click Quick Start Manual page 2

5. Schematic
VCC-3V3
GND
VCC-3V3
AN PWM
RST INT
R5
0R
CS TX
SCK RX
SCL
MISO
SDA
MOSI
+3.3V +5V
GND GND
MIKROBUS DEVICE CONN.
GND
6. Dimensions
42.9 mm / 1690 mils
VCC-3V3
R3
R1
3K3
2K2
LD3
LD1
Q1
PDTC114EU
R1
AADET
R2
GND
EXT_ANT
FORCE_ON VCC-3V3
RESET
R4
10K U1
TX FORCE_ON FORCE_ON
7
RX AADET AADET_N
8
NC
Quectel Quectel
9
RESET RESET
10
EXT_ANT EX_ANT
11
GND
12
L86-M33
VCC-3V3
GND GND
C1
100nF
GND
mm
42.9
LENGTH
25.4
WIDTH
HEIGHT* 8.6
* without headers
R1
PPS
R2
P$2
P$1
P$3
SIGNAL
CN2
GND
V_BCKP
VCC-3V3
1PPS PPS
6
V_BCKP V_BCKP
5
VCC
4
GND
L86 L86
3
TXD1 TX
2 GND
RXD1 RX
1
VCC-3V3
GND
E1
10uF
GND
7. External antenna connector
mils
1690
1000
GNSS click has a connector for an external
™
388.6
active antenna that could be used alongside,
or instead of the patch antenna that's
already on the module. To get one, search for
"GPS antenna" at www.mikroe.com/store
8. Code examples
VCC-3V3
R2
Once you have done all the necessary
3K3
preparations, it's time to get your click
LD2
up and running. We have provided examples
Q2
for mikroC
PDTC114EU
compilers on our Libstock website. Just
download them and you are ready to start.
GND
VCC-3V3
J2
9. Support
CN1
E2
C2
10uF
100nF
MikroElektronika offers free tech support
GND GND
(www.mikroe.com/support) until the end of
the product's lifetime, so if something goes
wrong, we're ready and willing to help!
10. Disclaimer
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specification and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
