Overhead Sport Bar
Storage Console
Installation Manual for '87-Current Wrangler YJ/TJ/JK
A
B
C
PARTS LIST:
A. STORAGE CONSOLE ASSEMBLY - QTY 1
B. COMPARTMENT LINER PADS - QTY 2
C. MOUNTING BRACKETS SPORT BAR - QTY 2
D. SCREW FOR MOUNTING BRACKETS - QTY 4
E. FLAT WASHER - QTY 4
F. 14.5" HOOK & LOOP STRAP - QTY 4
G. 11" HOOK & LOOP STRAP - QTY 4
#
14139.1110
B
D
E
F
TO REDUCE RISK OF SERIOUS INJURY OR PROPERTY DAMAGE:
READ ALL SAFETY MESSAGES AND UNDERSTAND ALL INSTRUCTIONS
AND PROCEDURE NOTICES BEFORE ATTEMPTING TO INSTALL OR USE
THIS PRODUCT.
RISK OF EYE INJURY! SAFETY GLASSES MUST BE WORN AT ALL TIMES
WHILE INSTALLING OR MAINTAINING THIS PRODUCT.
REQUIRED TOOLS:
SAFETY GLASSES
P3 PHILLIPS HEAD SCREWDRIVER
1/2" OPEN END WRENCH
by VDP
G
