Aircraft Dynamics RoboReel Triplex Manual

Cat No. 5478
I. Unbox Roboreel and Hooks, Install Wire Guide & Mount RoboReel
Wire Guide
RoboReel Triplex
Aircraft Dynamics Corporation - Utility Division
418 East Kiracofe Avenue, Elida, Ohio 45807
Tel: 800-874-4702 - 419-331-0371
www.aircraftdynamics.com
RoboReel Triplex Reel - designed for lineman to provide an easy and
safe means to unwind and rewind cumbersome wire and cable. Extremely
rugged, all-weather heavy-duty reel. Made of steel and zinc coated, the
RoboReel Triplex has eight adjustable arms that allow for a quick, easy
and secure means to load, unwind and rewind various coils sizes and
diameters. Coils can be simply rolled into the stand and clamped into
place with the adjustable arms. Wire is easily pulled or rewound through
a "smooth" guide. Reel can be installed on a floor or wall.
•
Eight Adjustable Arms.
•
Accepts coils with outside dia. from 26" - 32" (inside dia 14" - 20").
•
Coil widths can be up to 10-1/4."
•
Weight:58 lbs.
Accepts coils with
Outside dia. 26" - 32"
For shipping, Wire Guide is not attached to the base.
INSTALL SECURELY IN CORRECT POSITION AS
NEEDED FOR DRIVER OR PASSENGER SIDE
MOUNTING.
MOUNT ROBOREEL USING THE HOLES ON THE
BASE AND/OR SIDE OF ROBOREEL TO THE
DESIRED LOCATION ON YOUR VEHICLE.
www.aircraftdynamics.com
Made In USA
Accepts coils with
Inside dia. 14" - 20"
Coil widths can
be up to 10-1/4"
1
