TimeTec Smart Curtain Control Panel User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
w w w . i - t i m e t e c . c o m
SMART CURTAIN CONTROL PANEL
AUTOMATES YOUR BORING DAILY ROUTINE
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Curtain Control Panel and is the answer not in the manual?

Questions and answers

Summary of Contents for TimeTec Smart Curtain Control Panel

  • Page 1 . i - t i m e t e c . c o m SMART CURTAIN CONTROL PANEL AUTOMATES YOUR BORING DAILY ROUTINE User Guide...

  • Page 2: Product Brief

    . i - t i m e t e c . c o m PRODUCT BRIEF The TimeTec Smart Curtain Control Panel can use its touch buttons to control the electric curtain, or control by i-TimeTec smartphone App after the smart home system is setup.

  • Page 3: Technical Specification

    TECHNICAL SPECIFICATION Working voltage: AC 180V-50V 50Hz Standby current: <=4mA Working temperature: -10 - 55°C Working humidity: <=90%RH Communication distance: <=100M (open environment) Type of output: dry contact Dimension: 85mm x 85mm x 6mm Installation: flush mount Smart Curtain Control Panel...

  • Page 4: How To Use

    In the main menu, select Add Device, then scan the QR code of the device (QR code is on the back and also on the PCB after remove the front panel). Add the device to the TimeTec Smart Gateway or TimeTec Smart Camera Gateway.

  • Page 5: Wiring Diagram

    . i - t i m e t e c . c o m WIRING DIAGRAM Remark: This wiring example is based on the above control logic. If your curtain motor uses a differ- ent logic by default, please change the setting to make it match. Smart Curtain Control Panel...

  • Page 6: Installation

    Install the standard 86 electric box onto the wall Connect the electric wires to the switch correctly Fix the switch onto the 86 electric box with screws Fix the front panel onto the switch Finish the installation Smart Curtain Control Panel...

  • Page 7: Troubleshooting

    . i - t i m e t e c . c o m TROUBLESHOOTING If i-TimeTec Smartphone App control fail: Check whether the device is already added and connected to the TimeTec Smart Gateway. If Curtain control fail: Check the setting of your curtain motor, make sure it match the control logic as shown in this manual.
  • Page 8 . i - t i m e t e c . c o m © 00 Timetec Cloud Sdn Bhd. All rights reserved • 0100...
