Summary of Contents for SMOG-HOG SH Series
- Page 1 OPERATIONS MANUAL SH Series Models: SH-6 SH-10 SH-20 SH-40 SH-50...
-
Page 3: Table Of Contents
Blower Drive Outlet Vanes Cabinet Access Door (Electrostatics) Access Door (Drive Set) VIll. MAINTENANCE Cleaning Instructions Instructions for Replacing Ionizer Wire TROUBLESHOOTING Troubleshooting Procedures ORDERING PARTS APPENDIX SMOG-HOG Parts List SH Series Airflow Curves Wiring Diagrams SH Series Operations Manual... - Page 4 SH Series Operations Manual...
-
Page 5: Inspection Of Equipment
SMOG-HOG NOMENCLATURE I. INSPECTION OF EQUIPMENT SMOG-HOG electronic air cleaners are available in a Upon receipt of your SMOG-HOG, check carefully for any variety of configurations and sizes. Codes shown below possible shipping damage. Any damage to carton, skid, identify characteristics which might be built into a given etc. -
Page 6: Metal Truss Supported Ceilings
Figure 1 shows the NOTE:The SMOG-HOG should not be used for support of recommended method for suspending the units with chain. personnel or material. Check with local building Models SH-40 and SH-50 may be suspended by rod but code/structural engineer to ensure proper installation to roof are not approved for chain hanging. - Page 7 Figure 4 DIMENSIONS AND MOUNTING HOLE LOCATIONS (IN INCHES AND CENTIMETERS) SH Series Operations Manual...
-
Page 8: Ducted Installation
The power switch for operating the unit and any fused disconnect switch must be supplied by the customer and located remotely (not supplied as part of the SMOG-HOG). UL listed models are supplied by UAS with a motor starter and remote start/stop pushbutton switch as standard equipment. -
Page 9: Collection Cells
L. Access Door (Drive Set). A separate hinged door allows access to motor and blower for easy adjustment (see Figure 5). Figure 6 Replacing Ionizer Wire SH Series Operations Manual... -
Page 10: Instructions For Replacing Ionizer Wire
If the indicator light is out, proceed to isolate the difficulty as follows: Figure 7 Open the access door and depress the interlock switch. Checking Ionizer Voltage Check for presence of high voltage at cell and ionizer SH Series Operations Manual... -
Page 11: Ordering Parts
If the light remains out with the cell removed, close the To order replacement parts refer to “SMOG-HOG Parts door, discharge the high voltage with push-to-test buttons Lists” on page 9. Order through your local UAS and remove the ionizer(s). -
Page 12: Smog-Hog Parts List
02-0747 INSULATOR (CELL/CABINET INTERNALLY WIRED UNITS) 37-0012 INSULATOR (IONIZER/CABINET INTERNALLY WIRED UNITS) 37-0013 CONTACT SPRING, IONIZER- AND CELL-TO-CABINET OR -DOOR 36-0014 GROUND SPRING 36-0077 TRUSS HEAD SCREW 30-0082 ACORN NUT 30-0223 *UNITS WITH 6V INCANDESCENT LIGHTS SH Series Operations Manual... -
Page 13: Sh Series Airflow Curves
SH SERIES AIRFLOW CURVES SH Series Operations Manual... -
Page 14: Wiring Diagrams
SH Series Operations Manual... - Page 16 UNITED AIR SPECIALISTS, INC. LIMITED WARRANTY UAS warrants all equipment manufactured and sold by UAS against defective parts and workmanship for one year from date of shipment to Purchaser. This warranty is subject to the limitations in UAS’ standard terms and conditions provided to Purchaser. Any unauthorized repairs or modifications or abnormal use or misuse of equipment will void all warranties.
