Your safety, and the safety of others, is very important. To help you make informed decisions about
safety, we have provided installation and operating instructions and other information on labels and in
this guide. This information alerts you to potential hazards that could hurt you or others. It is not
possible to warn you about all potential hazards associated with this product, you must use your own
good judgment.
CARELESS INSTALLATION AND OPERATION CAN RESULT IN SERIOUS INJURY OR
EQUIPMENT DAMAGE. READ AND UNDERSTAND ALL SAFETY PRECAUTIONS AND
OPERATING INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS PRODUCT.
This guide identifies potential hazards and has important safety messages that help you and others avoid
personal injury or death. WARNING and CAUTION are signal words that identify the level of hazard.
These signal words mean:
WARNING signals a hazard that could cause serious injury or death, if you do not follow
recommendations.
you do not follow recommendations.
This guide uses NOTICE to call attention to important mechanical information, and Note: to empha-
size genera l information worthy of special attention.
Failure to observe these instructions could lead to severe injury or death.
Always use extreme caution when drilling on any vehicle. Make sure that all fuel lines, brake lines, electrical wires,
and other objects are not punctured or damaged when / if drilling on the vehicle. Thoroughly inspect the area to be
drilled (on both sides of material) prior to drilling, and relocate any objects that may be damaged. Failure to inspect the
area to be drilled may result in vehicle damage, electrical shock, fire or personal injury.
Always wear safety glasses when installing this kit.
Always use extreme caution when cutting and trimming during fitting.
Always remove jewelry and wear eye protection.
Never lean over battery while making connections.
Never route electrical cables:
- Across any sharp edges.
- Through or near moving parts.
- Near parts that become hot.
- Where cables may be damaged from flying debris.
Always insulate and protect all exposed wiring and electrical terminals.
Always install terminal boots as directed in installation instructions.
Always tighten all nuts and bolts securely, per the installation and operation.
Always perform regular inspections of all components and related hardware.
Failure to observe these instructions could lead to severe injury or death.
Components of this kit are designed to function with batteries rated at 12-30 amp-hr., and charging systems less than 1200
watt (100 amps @ 12 volt)
RECYCLE. Consult with your local environmental or health agency to determine recycle and disposal options.
WARN INDUSTRIES
INSTALLATION INSTRUCTIONS
DUAL BATTERY CONTROL KIT
Application: Side x Side (UTV)
CAUTION signals a hazard that may cause minor to moderate injury, if
WARNING
INJURY HAZARD
WARNING
INJURY HAZARD
Read installation and operating instructions thoroughly.
NOTICE
PAGE 1
Part Number: 77977
77978A1
