- Page 1 . i - t i m e t e c . c o m SMART SWITCH PANEL SMARTLY LIGHT UP YOUR HOME/OFFICE User Guide...
-
Page 2: Product Brief
. i - t i m e t e c . c o m PRODUCT BRIEF The TimeTec Smart Switch can use its touch buttons to control the light, or control by i-TimeTec smartphone App after the smart home system is setup. -
Page 3: Technical Specification
. i - t i m e t e c . c o m FEATURES Soft touch control button Beeper for operation LED indicator i-TimeTec Smartphone App control TECHNICAL SPECIFICATION Working voltage: AC 180V-50V 50Hz Standby current: <=4mA Working temperature: -10 - 55°C Working humidity: <=90%RH... -
Page 4: How To Use
Connect the switch to electricity wires, power it up so it will connect to the smart gateway by wireless. Touch the button to control the light, the beeper sounds The switch can also be controlled by the i-TimeTec smartphone App. Smart Switch... -
Page 5: Wiring Diagram
. i - t i m e t e c . c o m WIRING DIAGRAM Smart Switch... -
Page 6: Installation
INSTALLATION Install the standard 86 electric box onto the wall Connect the electric wires to the switch correctly Fix the switch onto the 86 electric box with screws Fix the front panel onto the switch Finish the installation Smart Switch... -
Page 7: Troubleshooting
. i - t i m e t e c . c o m TROUBLESHOOTING If i-TimeTec Smartphone App control fail: Check whether the switch is already added to the TimeTec Smart Gateway Check whether the switch is already connect to the TimeTec Smart Gateway by wireless IMPORTANT NOTICES The device shall be installed in a dry place without chemical corrosion. - Page 8 . i - t i m e t e c . c o m © 00 Timetec Cloud Sdn Bhd. All rights reserved • 0100...
