Kicker TRHDP Package Contents

Harley Davidson
for Reflashing Radios
Package Contents:
(1) Programmer Module
NOTE 1: MUST BE CONNECTED TO THE INTERNET
NOTE 2:
For motorcycles with:
Stock ECM: Follow the provided instructions below.
Power Commander: Disconnect the Power Commander from the ECM circuit. Reconnect the ECM to the stock
harness plug and then follow the provided instructions below.
Any Aftermarket ECM: Disconnect your aftermarket ECMand install your stock ECMto the bike harness. Follow the
provided instructions below. (For some ECMs this will mean reinitializing the aftermarket ECM when it is reinstalled)

INSTALLING THE SOFTWARE FOR A FIRST TIME USER

1. Download software program from http://technoresearch.com/index.php/support/downloads
2. Once the download completes, Run software installer.
3. If using the Kicker TRHDP connect to your computer using the supplied USB cable.
4. From the Icon on your desktop, Start the Centurion software.
5. Allow software to update, accept terms and conditions and select language to launch program.

PROGRAMMING LIKE A PRO

1. Remove side cover from left side of bike and locate the bottom 6-pin diagnostic plug.
2. Connect your programmer to this plug.
3. Turn ignition switch to the Accessory position.
4. Launch program
5. To connect to the bike, select the icon with two arrows facing each other
6. Once connected to the bike, select the icon with the Wrench on it
7. You will now see a drop-down menu. From this menu, you can read and reset DTC's, and complete programing for
adding KICKER Audio upgrade kits.

2 SPEAKER FRONT KIT

1. Select Radio speaker programing
2. Select 2 Speakers- Front Speaker Kit
3. Select Program Speaker
a. Follow on-screen directions, complete and look for Pass on the menu
4. Select from the drop-down menu: Radio Front Rear amp
5. Select Front and Start
a. Click enable and fl ash
b. Follow the on-screen directions (confi rm Pass)
6. Exit the program
®
Audio Programmer
(1) USB cable
TRHDP
(1) Diagnostic cable (1) Instructions
