Summary of Contents for Link NT07
- Page 1 User Guide NT07 Multi Tracker NT07_Multi_Tracker_User_Guide-BK&WH.indd 1 NT07_Multi_Tracker_User_Guide-BK&WH.indd 1 23/04/2020 18:41:51 23/04/2020 18:41:51...
- Page 2 LINK NT07 Multi Tracker The Multitracker helps you keep an eye on the people and things that matter to you the most. You can check current and past location, set alerts when the Multi Tracker leaves or enters a geofence, and receive alerts all through your smartphone.
-
Page 3: Product Specifications
1 Product Specifications Size: 42*42*16.5mm Input: 5V 500 mA Battery capacity: 500 mAh Net: 25g NT07_Multi_Tracker_User_Guide-BK&WH.indd 3 NT07_Multi_Tracker_User_Guide-BK&WH.indd 3 23/04/2020 18:41:51 23/04/2020 18:41:51... - Page 4 Operating Temperature: -20°C~60°C Storage Temperature: -40°C~85°C Waterproof: IP65 with silicon clip cover RF specifications: Output power Type Band limit (dBm) Band3 23±2.7 NB-IoT Band20 23±2.7 1.1 SAR Information This device complies with the RE Directive (2014/53/EU). Health (Article 3.1(a) of the RE Directive) Applied Standard: EN 50566:2017 SAR (5mm) ≤4.0W/kg(10g) 2 Learn about your NB-IoT Tracker...
- Page 5 2.1 Overview NT07_Multi_Tracker_User_Guide-BK&WH.indd 5 NT07_Multi_Tracker_User_Guide-BK&WH.indd 5 23/04/2020 18:41:52 23/04/2020 18:41:52...
- Page 6 2.2 Installing the SIM Card NT07_Multi_Tracker_User_Guide-BK&WH.indd 6 NT07_Multi_Tracker_User_Guide-BK&WH.indd 6 23/04/2020 18:41:52 23/04/2020 18:41:52...
- Page 7 2.3 Fitting the Silicon Sleeve Attention Please make sure the Data SIM card is activated, and you have topped it up with credit. The tracker will only accept a Nano size SIM card. Ensure the Tracker is powered OFF before inserting or removing the SIM card.
- Page 8 2.4 Charging the Tracker Connect the supplied USB charging cable to the Tracker and a USB charger then plug it into the socket. You can also connect the Tracker to charge on laptop or PC. Note: Always connect the Tracker to the cable before turning ON the power of the wall socket.
- Page 9 2.5 How to Set up NB-IoT Tracker 1. Insert the Nano SIM card in the SIM card slot. 2. Turn ON the power switch. 3. The indicator light turns red. 3 Getting Started For our APP to work correctly, we need a few permissions.
- Page 10 3.1 Download the “LinkTracker” APP, Register and Login Download the “LinkTracker” APP by scanning the QR code below. Make sure you scan the relevant QR code, consider your phone’s operating system. NT07_Multi_Tracker_User_Guide-BK&WH.indd 10 NT07_Multi_Tracker_User_Guide-BK&WH.indd 10 23/04/2020 18:41:53 23/04/2020 18:41:53...
- Page 11 NT07_Multi_Tracker_User_Guide-BK&WH.indd 11 NT07_Multi_Tracker_User_Guide-BK&WH.indd 11 23/04/2020 18:41:53 23/04/2020 18:41:53...
- Page 12 To pair a Multi Tracker with your APP, please scan the QR code at the back of the Multi Tracker after you Registered and Logged-in on the APP. 3.2 Pairing and unpairing the Tracker with your smartphone Pairing the Tracker: 1.
- Page 13 4 How to use NB-IoT Tracker and APP functions. 4.1 Key & Indication Lights There are two Reporting Frequency modes. 1. Default mode: Location information are recorded and uploaded to the server as and when the Tracker is in motion. In this mode the device is on standby, you must press SOS button to confirm and apply this setting.
- Page 14 Full power status: The green LED indicator illuminates for 51s. 4.2 Device manager NT07_Multi_Tracker_User_Guide-BK&WH.indd 14 NT07_Multi_Tracker_User_Guide-BK&WH.indd 14 23/04/2020 18:41:53 23/04/2020 18:41:53...
- Page 15 Add/ pair a new Tracker Battery remaining on the current Tracker Status of Tracker within Safety Zone Current location of the Tracker on map Current Tracker settings Change profile/name/Report Frequency and unpair NT07_Multi_Tracker_User_Guide-BK&WH.indd 15 NT07_Multi_Tracker_User_Guide-BK&WH.indd 15 23/04/2020 18:41:53 23/04/2020 18:41:53...
- Page 16 4.3 Map page NT07_Multi_Tracker_User_Guide-BK&WH.indd 16 NT07_Multi_Tracker_User_Guide-BK&WH.indd 16 23/04/2020 18:41:53 23/04/2020 18:41:53...
- Page 17 Electronic Fence (ON/OFF) Sets the reporting frequency intervals Set the geofence zone NB-IoT Network signal strength on the current Tracker Battery remaining on the current Tracker Tap to switch between Trackers Get mobile phone location Get Tracker location Display the Tracker history NT07_Multi_Tracker_User_Guide-BK&WH.indd 17 NT07_Multi_Tracker_User_Guide-BK&WH.indd 17 23/04/2020 18:41:53...
- Page 18 4.4 Account page NT07_Multi_Tracker_User_Guide-BK&WH.indd 18 NT07_Multi_Tracker_User_Guide-BK&WH.indd 18 23/04/2020 18:41:53 23/04/2020 18:41:53...
- Page 19 Edit the profile and name of the account holder Change and modify the Tracker settings Quick Installation Guide Change the account phone number and password APP version NT07_Multi_Tracker_User_Guide-BK&WH.indd 19 NT07_Multi_Tracker_User_Guide-BK&WH.indd 19 23/04/2020 18:41:53 23/04/2020 18:41:53...
-
Page 20: Troubleshooting
4.5 Troubleshooting Tracker won’t turn on! Possible reason • The battery is low Solution • Charge the battery • The Tracker will need to be repaired No network signal! Possible reason • SIM card not inserted correctly • No network coverage in your area •... - Page 21 Cannot locate my mobile phone on the map! Possible reason • Location tracking service not turned on Solution • Go to your mobile phone settings and turn on location tracking 5 Safety Warning • Only use the USB power cable supplied with the Tracker.
- Page 22 • Do not paint the device, this may lead to internal circuit failure. • Do not disassemble the device as this will invalidate the warranty. • Do not expose the Tracker to moisture or extreme heat (strong sunlight or direct radiation), or cold (persistent frost).
- Page 23 7 Warranty We offer a 1 year Warranty against manufacturers defects for Link Tracker. Within 1 year from the date of your purchase we will repair or replace any defective device at our expense. Simply send an email to info@ltsmartlink.com detailing the issue and include a few photos.
- Page 24 To open your warranty claim, please email info@ltsmartlink.com and provide the following information: • Order number • Current shipping address • Product name • Explanation of the problem 8. Legal notice • Google Play and the Google Play logo are trademarks of Google LLC. NT07_Multi_Tracker_User_Guide-BK&WH.indd 24 NT07_Multi_Tracker_User_Guide-BK&WH.indd 24 23/04/2020 18:41:53...
