Summary of Contents for Elbro AG DETECTOR 3000
- Page 1 DETECtOR 3000 EN Manual CAT III / 1000V CAT IV / 600V EN 61326-1 IEC 61243.3:2014 universaltester électrotesteur elettrotester electrical tester Detector 3000 Seite 0 / 11 Stand: 29.8.19 GB...
- Page 2 2. Test leads (on back side) 3. LED display 4. LCD display 5. On/ off and function button 6. Torchlight and hold button 7. Battery compartment 8. Sensor for cable break detection, NCV Detector 3000 Seite 1 / 11 Stand: 29.8.19 GB...
-
Page 3: Table Of Contents
The instruction manual contains information and references, necessary for safe operation and maintenance of the tester. Prior to using the tester (commissioning/ assembly) the user is kindly requested to thoroughly read the instruction manual and comply with it in all sections. Detector 3000 Seite 2 / 11 Stand: 29.8.19 GB... -
Page 4: Introduction / Product Package
Voltage tester is not a measurement device, it is only allowed to use for testing purposes. 1. Introduction / Product Package The Detector 3000 is a universally applicable testers for voltage, current, continuity and rotary field testing and various additional features. -
Page 5: Safety Measures
The tester may be used only in the measuring circuit category it has been designed for. Before and after use, always check that the tester is in perfect working order (e.g. on a known voltage source). Detector 3000 Seite 4 / 11 Stand: 29.8.19 GB... -
Page 6: Intended Use
2. Test leads (on back side) 3. LED display 4. LCD display 5. On/ off and function button 6. Torchlight and hold button 7. Battery compartment 8. Sensor for cable break detection, NCV Detector 3000 Seite 5 / 11 Stand: 29.8.19 GB... -
Page 7: Preparation For Tests
• 1. >50V AC/DC 2. >50VAC or >120 VDC Vibration is ON when a threshold voltage is >50VAC or >120VDC • Voltage polarity is indicated in following manner on LCD. • Detector 3000 Seite 6 / 11 Stand: 29.8.19 GB... -
Page 8: Low Voltage Mode
Hold the tester good in your hand and connect both probes to the object under test. • Phase-to-phase voltage is indicated by Voltage LEDs and LCD • • R LED lights up for Right rotary field L LED lights up for Left rotary field • Detector 3000 Seite 7 / 11 Stand: 29.8.19 GB... -
Page 9: Continuity Test
7.9. Cable break detection by NCV Switch into frequency measurement by pressing On/off /Function button repeated. LCD will • show NCV symbol. The NCV function is used to find e.g. after a cable breaks • Detector 3000 Seite 8 / 11 Stand: 29.8.19 GB... -
Page 10: Torch Light
Pull out the Battery door and replace the batteries. Insert new batteries according to the engraving on the Battery door. Re-assemble battery door. • Confirm that the Battery door case is properly locked prior to measurements. Detector 3000 Seite 9 / 11 Stand: 29.8.19 GB... -
Page 11: Technical Data
3V (IEC LR03 1.5V x 2) -15…55°C operation; Temperature -20…70°C storage; No condensation Humidity Max 85% RH Altitude up to 2000m Overvoltage CAT IV/690V CAT III/1000V Standard EN/IEC 61243-3:2014 Protection IP64 Detector 3000 Seite 10 / 11 Stand: 29.8.19 GB... -
Page 12: Cleaning And Storage
Do not expose the instrument to direct sun light, high temperature and humidity or dewfall. Remove batteries when the instrument will not be in use for a long period. ELBRO AG Steinackerstrasse 5 8180 Bülach info@elbro.com www.elbro.com Detector 3000 Seite 11 / 11 Stand: 29.8.19 GB...
