Summary of Contents for Teledyne M41d
- Page 1 M41d HBR3 Video Analyzer/Generator - Quick Start Guide M41d HBR3 Video Analyzer/Generator for DisplayPort Testing Quick Start Guide Rev: A6 Page 1 Rev A6 - May 29, 2020...
-
Page 2: Table Of Contents
4.2 Positioning/Orientation 4.3 Connectors and Controls 4.4 Gettting the M41d Up and Running Managing the M41d with ATP Manager from a PC 5.1 Install the M41d ATP Manager GUI Application 5.2 Setting the Instrument date and time Connecting the Devices Under Test 6.1 Connecting a DisplayPort Source Device Under... -
Page 3: Scope Of This Quick Start Guide
HDMI admin port (not the DisplayPort port) on the back of the M41d, before you power up the M41d system. If you have powered up the M41d prior to connected a display you will have to reboot the M41d. -
Page 4: About The M41D
(provided) is required and a keyboard is optional but recommended. In this case of the external display, the ATP Manager is running on the M41d itself but the ATP Manager GUI is displayed on the external monitor. These operational scenarios are shown below. - Page 5 M41d HBR3 Video Analyzer/Generator - Quick Start Guide ATP Manager Running on External Display (Source Test Example) ATP Manager Running on Host PC (Sink Test Example) Page 5 Rev A6 - May 29, 2020...
-
Page 6: Getting Started
M41d HBR3 Video Analyzer/Generator - Quick Start Guide 4 Getting Started This chapter explains what is involved in getting your M41d up and operating. What is in the M41d shipping box? When a Teledyne LeCroy quantumdata M41d is shipped it will contain the following additional items: •... -
Page 7: Connectors And Controls
M41d HBR3 Video Analyzer/Generator - Quick Start Guide Connectors and Controls The table below describes the M41d connectors and controls. M41d Configurations Information / Function Protocol Analyzer in M41d Front panel: ▪ A – DP HBR3 Rx ports for testing DP sources. One (1) Standard DP port;... -
Page 8: Gettting The M41D Up And Running
Gettting the M41d Up and Running Use the following procedures to get your M41d up and running. Remove the M41d from the shipping box and lay it flat or upright on your desktop or benchtop. Connect the M41d power cable (provided) to a suitable outlet (110-240V 50/60Hz). - Page 9 M41d as shown below. Optionally connect a keyboard to one of the other USB ports on the front or the back of the M41d. You can also use the virtual keyboards that present themselves in the ATP Manager. Page 9...
- Page 10 M41d HBR3 Video Analyzer/Generator - Quick Start Guide Power up the M41d via the power button on the front of the M41d. Notes: Regarding Power Button color: - The Power button will be Red if the power is off when a power connection in is in place in the back of the M41d.
- Page 11 M41d HBR3 Video Analyzer/Generator - Quick Start Guide Connect your DisplayPort source or sink device under test to the appropriate In/Rx or Out/Tx port on the front of the M41d. The following example shows an DisplayPort source device connected. You can fully operate the M41d through the ATP Manager using this connection scenario with a keyboard, mouse and external monitor.
- Page 12 M41d HBR3 Video Analyzer/Generator - Quick Start Guide application running on a host Windows PC as described in the following section. Important Notes Using External Monitor for ATP Manager Note 1: Selection of external monitor Due to HDCP 2.3 content protection schemes you will have to use an HDCP 2.3-enabled external monitor to view HDCP 2.3 protected...
-
Page 13: Managing The M41D With Atp Manager From A Pc
PC. You will have to first download and install the ATP Manager GUI application on your Windows PC. You will then need to connect your PC to the M41d over an Ethernet IP connection. These procedures are provided below. - Page 14 Connect your PC to the M41d using an Ethernet cable. The connection is made to the Rj45 jack on the back of the M41d labeled E1 to Network as shown below. The Ethernet IP connection from the host PC to the M41d can be accomplished through your corporate network or you can connect directly.
- Page 15 Corporate LAN PC Running ATP Manager with Ethernet Direct Connection Set the IP address of the M41d from the Other page under the Control window of the ATP Manager GUI. Select the Instrument Network Settings icon. A dialog box appears enabling you to set DHCP or specify an IP address.
- Page 16 Note: Be sure to use an IP address that is compatible with your corporate LAN or your PC if you are connecting directly. Power cycle the M41d with the power button on the front panel. A dialog box will appear on the ATP Manager. Select Shutdown.
- Page 17 Add icon or the + Add item on the Instrument pull-down menu identified below. The Add Instrument dialog appears enabling you to enter the name and IP information for the M41d that you are trying to connect to (below). Page 17...
- Page 18 You will see a series of messages on a dialog boxes describing the progress. One example is shown below: The M41d with the IP address you entered appears on the list in the ATP Navigator panel (below). The ATP Manager application will automatically connect to the M41d once you add the M41d to the application.
- Page 19 M41d HBR3 Video Analyzer/Generator - Quick Start Guide Once the connection is made the information about the connected M41d is available via the right click menu. The information is then displayed in a separate window. The information on the Instrument Information window tells you the firmware and hardware release and version information as well as what options you have.
-
Page 20: Setting The Instrument Date And Time
M41d HBR3 Video Analyzer/Generator - Quick Start Guide Setting the Instrument date and time This procedure describes how to set a M41d’s data and time. The procedure assumes that you have connected to an M41d through the external ATP Manager. - Page 21 M41d HBR3 Video Analyzer/Generator - Quick Start Guide The Select Date/Time… dialog box appears as shown below: Set the month and date and time by selecting from the Calendar and time dials. Page 21 Rev A6 - May 29, 2020...
-
Page 22: Connecting The Devices Under Test
Under Test This procedure describes how connect your DisplayPort source device to the M41d for testing. This example show the ATP Manager running on the M41d with the ATP Manager GUI on the external monitor. To connect your source DUT to the M41d: Connect the source device under test to the M41d DisplayPort In/Rx port as shown below. -
Page 23: Connecting A Displayport Sink Device Under Test
Connecting a DisplayPort Sink Device Under Test This procedure describes how connect your DisplayPort sink device to the M41d for testing. This example show the ATP Manager running on a host PC. To connect your sink DUT to the M41d:... -
Page 24: Connecting A Displayport Source And Sink For Passive Aux Channel Monitoring
This subsection describes the procedures for setting up passive monitoring between a DisplayPort HBR3-capable source and sink device. This example show the ATP Manager running on the M41d with the ATP Manager GUI on an external host PC. Page 24... - Page 25 DP cables may suffice, but the 95-00169 cable may still be used.) The base M41d is capable of Emulation AUX monitoring (when the M41d is either the Source or the Sink) using the provided standard DisplayPort cable. Please refer to the M41d User Guide for details.
-
Page 26: Upgrading Atp Manager
M41d HBR3 Video Analyzer/Generator - Quick Start Guide 7 Upgrading ATP Manager This section provides information about upgrading your M41d and M41d ATP Manager. Detailed procedures are not provided in this document. Please be sure to refer to the Release Notes for a specific release for detailed upgrade instructions. - Page 27 M41d HBR3 Video Analyzer/Generator - Quick Start Guide ATP Manager (GUI) either for the M41d or if you are using a host PC for Windows. This is the ATP Manager GUI that can be used to control all M41d instrument from a Windows PC.
