Summary of Contents for MouseOne ZeroCable
- Page 1 ZeroCable A ssembly & Installation __________...
- Page 2 Section 1 - Items included in your purchase Section 2 - Assembling your ZeroCable Section 3 - Assembling your ZeroCable on a mouse that isn’t in the Mouse Database Section 4 - Mouse Database Section 5 - Installing your ZeroCable ...
- Page 3 Name of parts 1x ZeroCable 2x black heat-shrink 1x clear heat-shrink 3x JST PH 2.0 5-pin connector ...
- Page 4 Step 3 - On the next page starts the database of all the mice ZeroCable is compatible with. Find your mouse and note the order of the colors. Step 4 - One by one insert the colored wires into their designated spots in the JST connector as ...
- Page 5 Mouse Database If your mouse is not listed in the Mouse Database on page 4, use this guide to attempt to install ZeroCable on your mouse. We can not guarantee that you will be able to install ZeroCable on every mouse. ...
- Page 6 Step 5 - One by one insert the colored wires into their designated spots in the JST connector as specified by the color order and placement of the old connector. As a reminder, the “nothing” signifies that no wire should be inserted in that spot. The small “hook” on the wires should be facing up when trying to insert them into the JST connector. ...
- Page 7 Mouse Database ABKO HACKER A660 - n othing w hite g reen b lack ed Asus ROG Sica - r ed w hite g reen b lack n othing ...
- Page 8 Logitech G502 - green w hite r ed b lack othing Logitech G600 - r ed w hite g reen b lack othing Logitech G Pro - green w hite ...
- Page 9 Roccat Kone Aimo - r ed b lack g reen w hite n othing Roccat Kone Pure EMP - n othing b lack w hite g reen r ed Roccat Kone Pure Military - n othing...
- Page 10 Step 5 - Plug the ZeroCable into the PCB (where you removed the old cable) Step 6 - Line up the second black heat-shrink to be ¼ in the mouse shell and ¾ outside of it ...
- Page 11 Switching your ZeroCable to another mouse is simple. Follow the directions on page 6 to remove the ZeroCable from the first mouse. Use a small flathead screwdriver to lift up each tab on the JST 5-pin connector. Carefully remove each wire from the connector. Then, follow the ...
