S C I E N T E M P C O R P .
Medical Freezers ~ Pharmacy Freezers ~ Culture Storage Freezers ~ Blood Storage/Blood Plasma Freezers
Adhesive Storage Freezers ~ Industrial/Manufacturing Freezers ~ Explosion Proof Freezers
Your Scientemp freezer has been pre-programmed at the factory and ready for use.
You only have to:
1) Plug your freezer into its own dedicated circuit and
2) Set your desired temperature on the controller
~~
To set the desired set point temperature, press and hold the * button, then while holding down the * press the UP
arrow to increase the set point temperature or press the DOWN arrow to decrease the set point temperature.
• When uncrating, do not discard the Dark Grey Styrofoam Sublids inside the
freezer.
*The Sublids are necessary to maintain correct temperature, moisture control and economy of
operation.
• Provide at least 3" of space around the freezer for ventilation. Avoid placing
the freezer in locations exposed to direct sunlight, heat registers or any other
heat source.
• Alarm On/Off switch should remain in the "Off" position until the freezer
reaches desired set point temperature. When the temperature has been
reached, turn the alarm switch to the "On" position.
• Cabinet should not be loaded with product until the cabinet has operated for
24 hours at the desired set point temperature.
Maintenance tips for your Scientemp Freezer:
•
Regularly remove any frost build up by using a plastic/wooden scraper.
• Check and replace batteries on Alarm Signal System and Chart Recorder (if
equipped) on a regular bases.
• Refrigeration compartment of the freezer, should be cleaned of dust and
debris about once a year (or more often if freezer is located where excessive
dust and dirt may occur)
~~This can be done by vacuuming carefully or by using forced air to blow the debris off.
(*) The freezer must be unplugged or removed from electricity before servicing.
3565 S. Adrian Hwy ~ Adrian, MI 49221-9253 ~ 1-517-263-6020 ~ fax 517-263-5492 ~ toll-free 800-968-2653
www.scientemp.com
Advertisement
Table of Contents
Related Manuals for Scientemp 43-1.7A
Summary of Contents for Scientemp 43-1.7A
- Page 1 Medical Freezers ~ Pharmacy Freezers ~ Culture Storage Freezers ~ Blood Storage/Blood Plasma Freezers Adhesive Storage Freezers ~ Industrial/Manufacturing Freezers ~ Explosion Proof Freezers Your Scientemp freezer has been pre-programmed at the factory and ready for use. You only have to:...
-
Page 2: Scientemp Corp
Adrian, Michigan 49221 Phone: 517-263-6020 Fax: 517-263-5492 Website: www.scientemp.com OPERATING INSTALLATION MANUAL MODEL 43-1.7A This cabinet has passed the QUALITY CONTROL INSPECTION and meets the high standards at Scientemp Corp. This inspection includes the complete refrigeration system, cabinet construction and finish. - Page 3 Below are important safety precautions that apply to this SCIENTEMP CORP. product: 3565 S. ADRIAN HIGHWAY ADRIAN, MICHIGAN •...
- Page 4 freezer improperly may jeopardize safety or cause undue 5 ELECTRICAL CONNECTIONS stress or damage to the refrigeration compressors. 5.1 Wiring Avoid opening the door for extended periods of time since chamber air will escape rapidly. Room air, which is higher This cabinet is equipped with a three-prong (grounding) plug in humidity, will replace chamber air and may cause frost to for your protection against shock hazards.
- Page 5 Seek medical attention as quickly as you can. warning system. It produces a penetrating, repeating sound to alert you. The Alarm system, used in conjunction with a SCIENTEMP low temperature cabinet, will monitor “temperature-rise” and *CAUTION: Wear protective clothing while either “power-failure”.
- Page 6 9 REMOVING & INSTALLING CABINET LID *CAUTION: HINGES ARE SPRING LOADED Remove the two top and one-bottom screws holding the lower portion of the hinge to the cabinet. While applying pressure to hold the hinge to the cabinet, remove the remaining bottom screw. Carefully let the spring tension lift the hinge from the cabinet.
-
Page 7: Instrument Panel Features
INSTRUMENT PANEL FEATURES This page can be photocopied and used as a visual aid and bookmark when working in other parts of the manual. Green LED: Setpoint 1 output indicator Right Red LED: Program Holdback Green Display: indicator Process variable or Function/Option Upper Red LED: Orange Display:... -
Page 8: Standard Warranty
Scientemp’s sole obligation under this warranty shall be limited, at its option, to either repairing or replacing any part of the cabinet determined by an authorized service agent to be defective. Scientemp reserves the right to repair the freezer at our facilities. -
Page 11: Part Description
Diagram Model # 43-1.7 Part Description Number or 85-1.7 5010-1.7 Outer Metal Lid Pan 1027-3 Tube Style Handle 1038 Hinge Assembly Call Lid Insulation 1003-1.7 Lid Gasket (Includes clips not shown) 1008-1.7 Plastic Lid Liner 1002-1.7 Dark Grey/Black Sub Lid (Styrofoam) 1095-1.7-L Breaker Strip Length 1095-1.7-W...
