DEEP SEA ELECTRONICS DSE335 Installation Instructions

TYPICAL WIRING DIAGRAM
DEEP SEA ELECTRONICS
DSE335 INSTALLATION NSTRUCTIONS
ACCESSING THE FRONT PANEL EDITOR (FPE)
Press and hold the (stop) and the
•
If a module security PIN has been set, the PIN number request is shown.
•
Press (tick). The first '#' changes to '0'. Press
•
to adjust it to the correct value.
Press (right) when the first digit is correctly entered. The digit you
•
have just entered shows '#' for security.
Enter the remaining digits of the PIN number. Press
•
back to adjust one of the previous digits.
Press (tick) after entering the final PIN digit. The PIN is checked for
•
validity. If the number is not correct, you must re-enter the PIN.
If the PIN has been successfully entered (or the module PIN has not been
•
enabled), the editor is displayed.
EDITING A PARAMETER
Press the Press the (left) or
•
you wish to view/change.
Press the (up) or (down) buttons to select the next parameter or
•
previous parameter within the current page.
When viewing the parameter to be changed, press the
•
The value begins to flash.
When editing the scheduler, press the
•
move between the various parameters of the scheduler.
Press the (up) or (down) buttons to adjust the value to the required
•
setting.
Press the (tick) button to the save the current value, the value ceases
•
flashing.
Press and hold the (tick) button to save all changes and exit the editor.
•
Alternatively, press and hold the
•
and exit the editor.
053-136
ISSUE 3
(tick) button.
(up) or (down)
(left) to move
(right) buttons to cycle to the section
(tick) button.
(left) or (right) button to
(stop) button to cancel all changes
