How to Measure Current Consumption
Measuring the current consumption of the DataHog2 logger is a very useful tool when diagnosing
problems and faults. Symptoms of high power consumption may include batteries expiring quickly or
suddenly, PSU Reset button will not hold in, and incorrect data on voltage inputs (caused by a drop in the 5V
excitation supply).
Remove all sensors and all connectors, Mains Hogs, Solar Hogs etc from the logger before taking any
measurements. If the currents measured exceeds the values shown below, please report all findings to Skye for
further advice.
If the currents measured are within the advised ranges, then the logger is OK, and maybe
sensors is drawing too much current through the logger. C
consumptions again. Repeat with each sensor individually until you find the faulty sensor.
There are 3 options to make the measurement described below. No 1 requires a power supply which
can measure current and voltage of the supply. No 2 involves desoldering a wire to make the measurement. No
3 involves making a reusable device useful for regular testing.
OPTION 1 - Using a Power Supply
Tools Required:
Power supply which can measure current and voltage of the supply
Laptop / PC, DataHog2 software & datalead
1. Remove the base from the logger
2. Remove the 6 C batteries
3. Set the power supply to 9VDC
4. Connect the power supply across the battery plate, positive to the red wire and negative to the black wire
5. Press the PSU Reset button, it should give one faint click
6. Press the Reset button.
7. Connect the PC datalead and start the logger software
8. Measure the current consumption in Main Menu mode, this should be 8.8 - 12 mA
9. Measure the current consumption in Log Mode, this should be 0.3 – 0.6 mA
OPTION 2 - Using an ammeter and desoldering a wire
Tools Required:
Good quality multimeter or ammeter, which will measure at least 0.1 mA
Soldering iron, solder and wicking
Laptop / PC, DataHog2 software & datalead
1. Remove the base from the logger
2. Remove the 6 C batteries
3. Desolder the red wire from the battery plate
4. Insert a fresh set of batteries
5. Connect the ammeter in series between the desoldered red wire and the terminal it was removed from
6. Press the PSU Reset button, it should give one faint click
7. Press the Reset button.
8. Connect the PC datalead and start the logger software
9. Measure the current consumption in Main Menu mode, this should be 8.8 - 12 mA
10. Measure the current consumption in Log Mode, this should be 0.3 – 0.6 mA
Skye Instruments Ltd
21, Ddole Enterprise Park, Llandrindod Wells
Powys LD1 6DF, United Kingdom
Technical Help
DataHog2
onnect one sensor and measure the current
TEL +44 (0)1597 824811
EMAIL skyemail@skyeinstruments.com
WEB http://www.skyeinstruments.com
one of the
Issue 1
