Installing the GF-Config Software
NOTE If you own other GoFlight hardware and have already installed the most current
version of software on your system, you do not need to install the software again.
Simply skip the software installation steps in the instructions below.
1. Get on line and go to www.goflightinc.com.
2. On the GoFlight home page click Support.
3. Click on "GF Config x.xx" to download the latest module drivers and configuration software.
4. Click "Run" or "Save" and follow the instruction to install the software.
If the software installer detects that GoFlight software is already installed on your system, it will prompt
you to overwrite. Click the Yes button to overwrite the existing version of GoFlight software. This is useful
if you wish to keep the configuration settings for other GoFlight modules installed on your system.
1
Congratulations on your purchase of a GoFlight GF-THR
737 Throttle Handles part of the extensive family of
GoFlight GF-AC Cockpit Control System modules. The
GF-THR 737 is designed to operate with a wide variety of
Aircraft and is sure to make your flight simulation
experience more realistic and enjoyable.
The
steps
configuration and operation of the GF-THR 737 Handles.
Following these instructions will help to get you up in the
"virtual skies" as quickly as possible.
Virtual Pilot Operating Handbook
GF-THR
B737 Throttle Handles
Cockpit Control System
below
will
assist
2012
GF-THR
in
the
installation,
Advertisement
Table of Contents
Related Manuals for GoFlight GF-THR
Summary of Contents for GoFlight GF-THR
- Page 1 If the software installer detects that GoFlight software is already installed on your system, it will prompt you to overwrite. Click the Yes button to overwrite the existing version of GoFlight software. This is useful if you wish to keep the configuration settings for other GoFlight modules installed on your system.
- Page 2 Locate four (4) switch wires soldered and glued to board. Separate wires (not from board but from one another) 1” from board mount. Gather your face plate, and new GF-THR handles. Run the handles with connecting wires through the slots on the metal cover (#3-#4) of cover paying attention to the Left and the Right handles being properly placed.
- Page 3 GF-THR 2012 Wiring Example Virtual Pilot Operating Handbook...
- Page 4 GF-THR 2012 Before you start setting up THR 737 handles First you need to calibrate your TQ6, so open your Control Panel and then Game Controllers. The TQ6 should be in the games controllers’ list. Choose your TQ6, and then click on properties. You should now see a picture of the TQ6 in the calibration window, like the example below.
- Page 5 GF-THR 2012 Configuring your GF-THR 737 Throttle Handles First, open GF-Config and configure your reverser arms. Open GF-Config and click on the picture of the TQ6 on the left side of the program window. Now, on the right side you will see the programming for the TQ6.
- Page 6 Disengage button can be programmed thru FSUIPC FSX; FS9 does not have this function. Example To Program the Auto Throttle Disengage use FSUIPC AP Panel Speed off setting. If you have any questions or problems setting up your GF-THR 737 Handles you can contact our Tech Support At techsupport@goflightinc.com or call 503-895-7020...
- Page 7 This product is warranted to the original purchaser to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase. During this warranty period, GoFlight Technologies, Inc. ® (“GoFlight”) will, at its option, repair or replace, at no charge, any component determined to be defective. The liability under this warranty is limited to the repair and/or replacement of the defect or defective part, and does not include shipping expenses.
