Summary of Contents for E-line ELI-ACVI-VD21-312MR
- Page 1 2MP IP Network IR Dome Security Camera ELI-ACVI-VD21-312MR ELI-ACVI-VD21-312R Control Motion Activated Warranty Resolution Recording eLineTechnology.com eLineTechnology.com eLineTechnology.com eLineTechnology.com eLineTechnology.com eLineTechnology.com 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835 800.683.6835...
-
Page 2: Important Safeguards And Warnings
Important Safeguards and warnings 1.Electrical Safety All installation and operation should conform to your local electrical safety codes. e power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC (24V AC) in the IEC60950-1. - Page 3 Important Safeguards and Warnings is series camera should be used in the speci ed working temperature. Please keep it away from electromagnetic radi- ation objects and environments. Please keep the camera ventilated. Do not allow water and other liquid into the camera. 6.Accessories Be sure to use all the accessories recommended by the man- ufacturer.
-
Page 4: General Introduction
General Introduction 1.1 Overview is series megapixel HD camera conforms to the HD-CVI standard. It supports high-speed, long-distance video transmission without any de- lay. It can be controlled by the DVR conforming to HD-CVI. 1.2 Features • High-performance CMOS image sensor, megapixel de nition. •... - Page 5 Dome Framework Important Dimensions of Cameras may vary depending on your mod- el. If you are having trouble nding the dimensions you can nd the measurements by using a caliper or try your best using a ruler. To nd the circumference of the bottom of the camera use the following formula: Diameter of circle x 3.14(pi)
- Page 6 HD-CVI Glass Housing Dome Cover Dome Cover Dome Enclosure Dome Enclosure IR Light IR Light IR Light Dome Module Dome Pedestal Power Input Port Video Output Port SD/HD Switch Cable...
-
Page 7: Dome Installation
When the Standard de nition/high de nition switch control cable is short circuited, system outputs standard de nition video. Otherwise, when the circuit is open, system outputs the high de nition video. Dome Installation Important Before the installation, please make sure the installation surface can sustain at least 3X weight of the bracket and the camera. - Page 8 Step 1 Take the installation position map from the accessories bag and put it on the sur- face of the ceiling or the wall according to the cable exit position. Drill three holes according to the installation position map and then take three expansion bolts from the accessories bag and put them into the holes you just drilled.
-
Page 9: Hd-Cvi Series Dvr Settings
Menu HD-CVI Series DVR settings e following operation and interfaces is for reference only. Please refer to the HD-CVI series DVR user’s manual for detailed information. A er connecting the camera to the HD-CVI series DVR go to Main Menu ->Setting->System->PTZ. - Page 10 On the preview interface, right click mouse and then select PTZ; you can see an interface shown as below. Click Iris “+” to open menu or con rm current operation. Click up/down but- Click Iris “+” to open menu or con rm current operation. Click up/down but- ton to view all the items on the le pane of the following list.
