CityGrow Systems CG102BS-R User Manual

Zigbee base station

Advertisement

CG102BS-R
Z
B
B
S
IG
EE
ASE
TATION
U
M
SER
ANUAL
CG102BS-R
ZigBee Base Station
V
1.1
ERSION
12 F
, 2020
EBRUARY
Disclaimers and Copyright
Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the
manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as
insuring anyone against liability for infringement of letters patent.
Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however,
CityGrow Energy Systems Limited makes no representation, warranty, or guarantee in connection with this publication
and hereby expressly disclaims any liability or responsibility for loss or damage resulting from its use or from the use
of any product or methodology described herein; for any violation of any federal, state, or municipal regulation with
which this publication may conflict; or for the infringement of any patent from the use of this publication. Nothing
contained in this publication should be viewed as an endorsement by CityGrow Energy Systems Limited of any particular
manufacturer's products.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG102BS-R and is the answer not in the manual?

Questions and answers

Summary of Contents for CityGrow Systems CG102BS-R

  • Page 1 CG102BS-R TATION ANUAL CG102BS-R ZigBee Base Station ERSION 12 F , 2020 EBRUARY Disclaimers and Copyright Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as insuring anyone against liability for infringement of letters patent.
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 3: Table Of Contents

    Table of content Introduction ....................1 Understanding the product ................2 Dimension ....................3 Power-up the CG102BS-R ................4 Device List Upload ..................5 Device Control .................... 5 Specification ....................6...
  • Page 4: Introduction

    1. Introduction Thank you for choosing CityGrow’s product. CG102BS-R ZigBee Base Station is highly- functional, user-friendly and installation-friendly. The CG102BS-R is a ZigBee network gateway specially designed for CityGrow home automation system. Description ZigBee wireless remote control. Based on IEEE 802.15.4.
  • Page 5: Understanding The Product

    2. Understanding the product 1. Status LED 2. DC Socket 3. Ethernet RJ-45 port 4. Function Test Button LA N DAT A RES E T FUNC. 5. Reset Button 6. Data Port for maintenance...
  • Page 6: Dimension

    3. Dimension 130 mm 130 mm 40 mm...
  • Page 7: Power-Up The Cg102Bs-R

    FUNC. Local Ethernet from DC Socket Router  Connect the CG102BS-R to the local Ethernet via the Wi-Fi router.  Insert the DC Plug into the DC socket of the CG102BS-R.  Plug the transformer to the AC220V socket. IMPORTANT NOTE: Please ensure the network connection is normal and stable at the installation location.
  • Page 8: Device List Upload

    A list of the CityGrow Home Automation devices should be uploaded to the CG102BS-R ZigBee Base Station before the CG102BS-R can operate with your home automation system. For the details on how to upload the device list to the CG102BS-R, please refer to the user manual of the HomeNET Planner 2 Software.
  • Page 9: Specification

    7. Specification Item Description Power supply Powered by external AC adaptor DC6V 1A ZigBee wireless communication ZigBee wireless remote control Based on IEEE 802.15.4 Ethernet port Fast Ethernet: UTP Cat5, EIA/TIA-568 100-ohm screened twisted-pair (STP) Supported configuration Maximum number of devices: 120 ZigBee devices ZigBee device type: Dimmer, Switch, Socket, Curtain, IR, Fan Coil control, Thermostat Remote access...
