Hocoma LokomatPro Quick Start Manual

"What is the difference between the patient setup with the LokomatPro and the LokomatPro with FreeD?"
1. Leg lengths Measure upper and lower legs, adjust the orthoses and enter the values in
the software.
2. Cuffs Select the cuffs and attach them to the orthoses.
3. Harness
Select the harness and leg loops. Fix the harness on the patient.
4. Lift Patient Attach the patient to the support frame and lift the patient. Close the swivel
door and lower the orthoses.
5. Hip Alignment
Adjust the height of the Lokomat by placing the hip cushions directly above
the greater trochanter. Set the pelvic depth and width using the dedicated
hand wheels. Fix the pelvis by fastening the strap around the pelvis and by
adjusting the orthosis to the rings on the harness.
Question and Answer: Lokomat
LokomatPro LokomatPro with FreeD
Measure upper and lower legs, adjust the orthoses and enter the values in the software.
Select the cuffs and attach them to the orthoses.
most patients. If this is not the case, the middle cuffs can be
Select the harness and leg loops. Fix the harness on the patient.
Attach the patient to the support frame and lift the patient. Close the swivel door and lower the orthoses.
the "Center Pelvis and BWS" button on the therapist screen and open the pelvic orthosis to its maximum
width.
Adjust the height of the Lokomat by aligning the greater trochanter with the
pelvic depth by turning on the hand wheel and the
open, push button and pull). Attach the patient harness to the orthosis by
harness.
1/2
The upper cuffs are delivered in sizes 9 and 7 and should fit
used.
white plastic indicators.
pelvic width by pushing inwards on the pelvic cushions (to
buckling the pelvic straps on the
© Hocoma, www.hocoma.com
Press
Adjust the
