- Page 1 Plus-X ICRU Installation and Operation Manual...
-
Page 2: Table Of Contents
Set a Static IP Address ......................4 Complete the Network Settings ....................5 Connecting the Plus-X ICRU to the ARC Plus ................5 Using a Status Channel to Monitor the State of a Relay Output ........... 6 Connecting Command Channel Outputs ..................6 Pairing Relays ........................... -
Page 3: Introduction
The Plus-X Integrated Command Relay Unit is used to connect site equipment to the ARC Plus. Each Plus-X ICRU connects up 16 relays or 8 pairs of raise/lower relay outputs. Plus-X ICRU units are connected to the ARC Plus via LAN or WAN. Up to 32 Plus-X devices can be connected to each ARC Plus. -
Page 4: Initial Connection Using Dhcp
* Hostnames can be used in either upper or lower case. Initial Connection Using DHCP Connect the Plus-X ICRU to your LAN and apply power. If this is the first power-up for a new unit or the first network connection after execution of a master-initialization, the Plus-X ICRU will issue a DHCP request for an IP address. -
Page 5: Initial Connection Without Dhcp
If your network does not support the DHCP protocol, the Plus-X ICRU’s request for a dynamic IP address will fail. If this happens, the Plus-X ICRU will assign itself the default static IP address of 192.168.0.100. To access the unit, it will be necessary to connect your PC directly to the Plus-X device using a crossover LAN cable or using a simple Ethernet switch. -
Page 6: Set A Static Ip Address
Select “Use the following IP address:” and enter an address of the form 192.168.0.x, where x is any value between 1 and 255 except 100 which is the Plus-X default IP address. Also set the subnet mask to 255.255.255.0 as shown above. Check the box “validate settings upon exit”... -
Page 7: Complete The Network Settings
Connecting the Plus-X ICRU to the ARC Plus If you have not already done so, install the Plus-X ICRU in the equipment rack. If you wish, you may distribute Plus-X units in multiple racks, or at different locations. To add the channels from the Plus-X ICRU to the ARC Plus: 1. -
Page 8: Using A Status Channel To Monitor The State Of A Relay Output
IP address and Port, as already configured on the Plus-X ICRU. 4. Check the box marked Map Default Set of Channels to add all channels for this Plus-X unit to the ARC Plus and enter a starting channel number for assignment of these channels in the ARC Plus. -
Page 9: Pairing Relays
C NO NC C NO NC Pinouts for raise channels (left side of Plus-X ICRU rear panel) are identical to the pinouts for lower channels (right side of Plus-X ICRU rear panel). Attach wiring for each channel using the mating connector blocks supplied in the accessory kit. -
Page 10: Restoring Factory Configuration
Friday, 9AM to 5PM Eastern time. Warranty Burk Technology, Inc. warrants the Plus-X ICRU to be free of defects in materials and workmanship for a period of 24 months from the date of purchase. Equipment will be repaired or replaced at the option of Burk Technology and returned freight prepaid to the customer. -
Page 11: Appendix A: Specifications
1A fuse protection Connectivity: Ethernet connection to ARC Plus Channel Capacity: 16 relays (individual or up to 8 raise/lower pairs) Output Types: C, NO, NC relay outputs; momentary or latching; 5A, 240VAC Plus-X ICRU Installation and Operation Manual Rev B...
