Summary of Contents for Autoease TL105
- Page 1 AUTO EASE POWER LIFTGATE MANUAL TESLA MODEL S TL105-3085...
- Page 2 4. Make protections of the car dash board, plastic and metal surface, in case scratches during installation. 5. Secure all the cables/wires in the car in case loose contact while driving. 6. The installation will take 1-2 hours, please follow the manual patiently. facebook.com/autoease...
-
Page 3: Part List
PART LIST Pole Control Box Power Cable Decoder Gate Drill Button TOOLS (not included) Screw Spanner Plastic Driver Wrench REMARK: Pictures for reference only, they may look different or not reflect the real product while products being updated. facebook.com/autoease... -
Page 4: Control Box
SCHEME CONTROL BOX ① Control box power ② Left pole power ③ Left pole control ④ Right pole power ⑤ Right pole control ⑥ N/A ⑦ N/A ⑧ Button control facebook.com/autoease... - Page 5 1. Use plastic wrench to remove the panels in the rear door. 2. Use original pole bracket to fix our poles (bottom) 3. Use original pole bracket to fix our poles (top) 4. Routing the poles hall cable through the plastic cover as picture. facebook.com/autoease...
- Page 6 5. Remove the plastic panel of rear door (right) for routing the cables and hide inside. 6. Remove the plastic panel below glove box in the passenger’s side 7. Remove the plastic panel of glove box in the passenger’s side 8. Open the engine cover plate facebook.com/autoease...
- Page 7 10. Route the power cable through slot in the passenger’s side 11. Locate the car OBDii port under driver’s seat, connect to our OBD adapter for fob/remote control. OBD adapter for our kit use 12. Fix the control box to the rear door with a screw like picture. facebook.com/autoease...
- Page 8 13. Locate original lock connector, connect to the liftgate lock adapter 14. Drill hole for installing our tail gate control button 15. Tail gate button installed 16. Installation finished! facebook.com/autoease...
-
Page 9: Frequently Asked Questions
4. Gate cannot close to the end and not locked A. a) slightly adjust the lock b) check if left/right poles are reversed c) check control box wiring d) check if not using screws in the box e) remove a little cushion in the latch facebook.com/autoease... - Page 10 A. Check if you have manually close the gate to initialize the system. If not, try this – manually open the gate to a proper height, long press gate button until you hear a beep, click button once to close gate, done. facebook.com/autoease...
