Specification

USB 2.0 Port
Ports
Power Mode
Output Voltage (per port)
Output Current (per port)
Micro SD Card Reader
Speed
Support Memory Card
Serial Port
Serial Ports
RS-232 Signals
Maximum Bit rates
Serial Configuration
UART FIFO Buffer Size
USB-2COM-BB
Downstream
Upstream
Two RS-232 ports
DCD, RxD, TxD, DTR, GND, DSR, RTS, CTS , RI
921,600 bps
Data bits : 7,8
Parity
Stop bits : 1, 2
Each port with 128 Bytes FIFO for transmit
and 384 bytes FIFO for receive.
Dual RS-232/USB/Micro SD Cape for BeagleBone Black & BeagleBone
2
1
Self Power Mode
+5V DC
500 mA (max)
480 Mbps USB 2.0 transfer speed
Micro SD/ SDHC/ SDXC
: None, Odd, Even, Mark , Space
