Modulus RC-1 Preliminary User's Manual

Table of Contents

Quick Links

Download this manual

Contents

Unpack the Modulus Remote Control .............................................................................................. 1

Charge the Modulus Remote Control ............................................................................................... 2

Turn on the Modulus Remote Control .............................................................................................. 2

Install the USB Receiver/Dongle ...................................................................................................... 2

Short-Press vs. Long-Press ............................................................................................................... 3

Front Panel Button Locations ........................................................................................................... 4

Modulus Remote Control Front Panel Functions ............................................................................. 6

A/V Mode, Aux Mode, TV Mode Buttons ....................................................................................... 8

Using the Modulus Remote Control's Air Mouse ............................................................................ 9

Using the Modulus Remote Control's Rear-Panel QWERTY Keyboard ......................................... 9

Using the Modulus Remote Control's Earphone Jack for Private Listening .................................. 10

Tips ................................................................................................................................................. 10

Specifications and Support ............................................................................................................. 10

Introduction

The Modulus Remote Control is a multi-function controller for the Modulus All-In-One Media System

(MMS). With its air mouse capabilities, voice control and rear-panel QWERTY keyboard, the Modulus Remote

Control makes it easy to configure and control the MMS and to play and enjoy live, recorded and streaming

media of all types. You can even use the Modulus Remote Control as a universal remote for your TV or other

devices. Enjoy!

Unpack the Modulus Remote Control

The Remote Control comes packed with its Charging Cradle, Power Supply and USB Receiver/Dongle

in a separate box inside the MMS carton.

Page 1

Modulus Remote Control

Preliminary User Manual

Figure 1: Modulus Remote Control with Charging Cradle, Power Supply and

USB Receiver/Dongle

Table of Contents

Need help?

Do you have a question about the RC-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Modulus RC-1

Page 1: Table Of Contents
Control makes it easy to configure and control the MMS and to play and enjoy live, recorded and streaming media of all types. You can even use the Modulus Remote Control as a universal remote for your TV or other devices.
Page 2: Charge The Modulus Remote Control
Turn on the Modulus Remote Control The Modulus Remote Control ships in a power off state. Once the Remote Control is fully charged, turn it on by holding down the INFO Button until the blue Wireless Signal Indicator LED flashes repeatedly.
Page 3: Short-Press Vs. Long-Press
Short-Press vs. Long-Press Many of the Modulus Remote Control’s Buttons have two functions accessed by a short-press vs. a long-press. This is very similar to the operation of your smart phone where a tap (short-press) activates a different function from a tap-and-hold (long-press). The following table explains the two functions of each Button.
Page 4: Front Panel Button Locations
Front Panel Button Locations The Modulus Remote Control’s Buttons are conveniently organized by function as shown in Figure 5 . The discussions in Section 7 begin at the top of the Modulus Remote Control and move downwards. Page 4...
Page 5 Short Press: Live TV Program Guide Power Long Press: Help Turns auxiliary devices (TV, receiver, etc.) Comm Skip on or off. Does not turn Modulus on/off. Short Press: Skip a commercial forward Menu Long Press: Skip a commercial backwards Short Press: Display an options menu...
Page 6: Modulus Remote Control Front Panel Functions
Power Button Turns auxiliary devices (TV, etc.) on or off. Does not turn Modulus on/off. See Figure 5 and Section 8. Note: If you program the Remote Control to control your TV or other devices (see Section 8), Press the A/V Mode, Aux Mode or TV Mode Button and then the Power Button to turn those devices on and off.
Page 7 Menu Button Short-press the Menu Button to display a context-sensitive menu of options. Long-press the Menu Button to activate search. Guide Button Short-press the Guide Button to display the MMS’s installed streaming apps, recorded DVDs and Blu- Rays and other media. Long-press the Guide Button to display the electronic program guide (EPG) in any streaming app or when watching live TV.
Page 8: A/V Mode, Aux Mode, Tv Mode Buttons
Note: Long-press the Info Button to put the Modulus Remote Control into Deep Sleep mode. You may wish to do this to conserve battery life when you’re going on an extended vacation. To restore the Remote Control to normal operation, hold down the Info Button until the blue Wireless Signal Indicator LED illuminates (see Figure 3).
Page 9: Using The Modulus Remote Control's Air Mouse
Using the Modulus Remote Control’s Air Mouse The Air Mouse is a great way to navigate streaming services and can be used on any Modulus screen. Short-press the Mouse Button to enter the Air Mouse mode. Hold the Remote Control in either hand and move it up and down and left and right to move the mouse cursor on the screen.
Page 10: Using The Modulus Remote Control's Earphone Jack For Private Listening
Control’s left edge. Tips Modulus encourages you to explore your Modulus All-In-One Media System’s many functions and capabilities. Here are some quick tips to help you in that adventure. 1. Press Menu in most screens to see a list of additional features and options.
Page 11 Weight of the base：90gm Re-Paring the Modulus Remote Control The Remote Control and its USB Receiver are paired at the Modulus factory. If the Remote Control loses connection with the USB Receiver, you can re-pair the two as follows: 1. Important: Set the Remote flat on a table when going through this process to calibrate its gyroscope.
