Summary of Contents for DAMOACAM CK800QHD
- Page 1 Carkey Type CAMCORDER Quick Guide CK800QHD DAMOACAM-SIX TECH USA www.six-tech-usa.com...
- Page 2 Name and Parts ① 5 pin port (PC Connection / Charging) ② Charge LED (Green)/ REC LED (Blue) ③ Reset button ④ Power On / Off button ⑤ REC button ⑥ Photo ⑦ Dummy button ⑧ Release button to open the cap ⑨...
- Page 3 Charging Camcorder Please make sure that turn off the power before charging. < > ① 5pin port DC Adapter ⑩USB Cable ② Charge/REC LED On charging- Green LED illuminate Open Full charging – Green LED goes out 1) Connect ⑩(USB Cable) to ①(5pin port) and DC Adapter 2) The Charge LED indicator illuminates green indicating the device is in charging mode.
- Page 4 2) Recording In standby mode state, press ⑤REC button. Recording starts with two vibrations. REC LED(blue/Red) blinks when it is recording. 3) Pause Recording Press ⑤ once if you want to pause it during the recording. The recording is stopped with a single vibration. (The blue LED is solid without blinking.) If you want to starts recording again in standby mode, press ⑤...
- Page 5 In standby mode state, press ⑥Photo button. Once pressed, a single picture is taken with a single vibration. Whenever you press ⑥ button, each photograph is taken continuously. LED(Red) blinks when picture is taken. 3) Power Off To power off, long press ④ for more than 4 seconds at any time. Power turns off with two vibrations.
- Page 6 Please make sure that turn off the power before Playback on PC/Notebook. < > ① 5pin port Notebook ⑩USB Cable ② Charge/REC LED Open 1) PC / Notebook Connect 1.1 Connect ⑩(USB Cable) to ①(5pin port) and USB port of PC/Notebook. 1.2 The Charge LED indicator illuminates green and blue indicating the device is connected with PC/Notebook.
- Page 7 To set up Menu and Password, you must first install DMC_Tool S/W to your PC. DMC_Tool and setup.exe is in the removable disk of camcorder. 1) To install DMC_Tool on the wallpaper of PC 1.1 Connect ⑩(USB Cable) to ①(5pin port) and USB port of PC/Notebook. 1.2 The Charge LED indicator illuminates green and blue indicating the device is connected with PC/Notebook.
- Page 8 image is erased and overwritten.) 5Min – Unit of recording time 5 minutes. (When the memory capacity is full, the first image is erased and overwritten.) 10Min - Unit of recording time 10 minutes. (When the memory capacity is full, the first image is erased and overwritten.) 2.2.4 Motion Detection...
- Page 9 2.3.4 Auto Rotation OFF – Recording without rotate ON – Regardless of the camcorder upside down, the images are rotated automatically and filmed normally. * This function is not executed during recording, it is valid before filming. 2.3.5 Audio OFF – Turn off the sound recording ON –...
- Page 10 Press “OK” button to complete the password settings. (Without the password, the image file will not be visible and will not be able to play. To play, you must enter your PIN.) * Password settings are made up of 4 digits. Never forget your password because nobody can open it without a password.
-
Page 11: Specification
Once the PIN is set, you are prompted to enter it every time you open video files. If you haven't set up a password, you can play the file without limitation. Apply After checking all options and setting PIN, press “Apply” to finish the Menu Settings. Specification ◆... - Page 12 Information CK800QHD - Full HD 1920*1080 / 60FPS Video Size - Quad HD 2560*1440 / 30FPS (Resolution and Frame) - Ultra HD 2880*2160 (4:3 SCALE) / 24FPS Picture Size - Upto 12MP Image Sensor - Sony EXMOR image sensor Image Compression Codec - H.264 / MOV...
