Instruction Manual
Wingspan : 1420mm
Length
g
Weight
Radio
Engine
: 1320mm
: 3300g - 4000g
: 5 servo + 1 servo retract / 6 channel
: 61-75 two stroke

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMC Sea Fury and is the answer not in the manual?

Questions and answers

Related Manuals for ELEFUN SMC Sea Fury

Summary of Contents for ELEFUN SMC Sea Fury

  • Page 1 Instruction Manual Wingspan : 1420mm Length : 1320mm Weight : 3300g - 4000g Radio : 5 servo + 1 servo retract / 6 channel Engine : 61-75 two stroke...

  • Page 2: Kit Contents

    Instruction Manual SEA FURY Instruction Manual STINSON - EP KIT CONTENTS: We have organized the parts as they come out of the box for better identification during assembly. We recommend that you regroup the parts in the same manner. This will ensure you have all of parts required before you begin assembly.
  • Page 3 Instruction Manual SEA FURY Installing the aileron servos and linkage Remove the covering from the top of the wing. Remove the covering from the aileron servo box (at the bottom of the wing). Insert the thread into the wing. Tape the servo lead into the end of the thread. Pull the servo lead out.
  • Page 4 Instruction Manual SEA FURY Mark the holes from the control horn onto the bottom of Install the control horn onto the aileron. the aileron. Install the clevis to the aileron pushrod. Insert the clevis into the control horn. Cut away the aileron pushrod. Bend “L”...

  • Page 5: Joining The Wing Halves

    Instruction Manual SEA FURY Joining the wing halves Center line Draw a center line. Remove the covering from the rear of the wing. Glue the wing joiner to the wing, using the epoxy glue. Apply the epoxy into the wing section. Glue the wing by epoxy.
  • Page 6 Instruction Manual SEA FURY Insert the landing gear into the block and mark four holes Take out the landing gear and drill four holes into the block. onto the block. Silicone Metal clevis Metal Pushrod Attach the metal rod to the landing gear. Install and secure the landing gear into the block.
  • Page 7 Instruction Manual SEA FURY Install two metal connector to the servo arm of the gear servo. Install the servo arm and attach two rods to the metal connector. Close position Open position...
  • Page 8 Instruction Manual SEA FURY Installing the horizontal stabilizer and the vertical stabilizer Make a center line onto the horizontal. Remove the covering from the rear of the fuselage. Make the slot from the fuselage for rudder hinge. Attach the horizontal to the fuselage and check it. Check the horizontal and the wing as shows.
  • Page 9 Instruction Manual SEA FURY Remove the covering from the rear of the vertical. Insert the hinge into the slot. Attach the horizontal and the vertical to the fuselage. Mark the shape of the vertical onto the top of the horizontal. Remove the covering from the top of the horizontal.
  • Page 10 Instruction Manual SEA FURY Installing the elevator and rudder pushrod The control horn. Install the control horn onto the elevator. Make the same way for the second control horn. Remove the covering from the slot. Attach the clevis to the elevator pushrod. Insert the silicone tube into the clevis.

  • Page 11: Installing The Tail Gear

    Instruction Manual SEA FURY Make the same way for the second elevator pushrod. Install control horn onto the rudder. Remove the covering from the slot. Insert the rudder pushrod into the fuselage. Attach the clevis to the control horn. Installing the tail gear The tail gear.
  • Page 12 Instruction Manual SEA FURY Install the two nylon clasp onto the bottom of the rudder. Glue the two nylon clasp C.A glue. Install the wheel and the collar into the tail gear. Install the tail gear into the fuselage and secure it. Installing the servo of the elevator and rudder Install the elevator servo and secure it.
  • Page 13 Instruction Manual SEA FURY Attach the nylon clasp. Install the rudder servo and secure it. Cut away the rudder pushrod. Bend “L” the rudder pushrod. Attach the nylon clasp. Installing the fuel tank and the engine The engine mount. Install the engine mount.
  • Page 14 Instruction Manual SEA FURY Prepare the stopper for the tank. Secure the stopper. Install the silicone tube of the tank (not included). Slide the fuel tank to the fuselage. Secure the fuel tank by C.A glue. Attach the engine to the engine mount and mark four holes. Drill four holes onto the engine mount.
  • Page 15 Instruction Manual SEA FURY Glue the nylon housing. Attach the throttle rod to the arm of the carburator. Install the engine and secure it. Secure the muffler. Install the throttle servo. Install the metal connector to the servo arm. Secure the throttle rod. Cut away the throttle rod.

  • Page 16: Installing The Switch, Receiver And Battery

    Instruction Manual SEA FURY Installing the switch, receiver and battery Place the switch to the fuselage. Install the switch. Battery Receiver Install the receiver and battery. Install the plastic engine cover Glue the block of wood to the plastic cover. Glue the plastic cover to the cowl.
  • Page 17 Instruction Manual SEA FURY Insert the plate of the spinner. Install the propeller. Install the propeller.

  • Page 18: Control Throws

    Instruction Manual SEA FURY BALANCING CONTROL THROWS 1. It is critical that your airplane be balanced correctly. 1. We highly recommend setting up a plane using the Improper balance will cause your plane to lose control throws listed. control and crash. 2.
  • Page 19 Instruction Manual SEA FURY I/C FLIGHT GUIDELINES Operate the control sticks on the When ready to fly, first extend the transmitter and check that the control transmitter aerial. surfaces move freely and in the ALWAYS land the model INTO the CORRECT directions.
