Init NT-WGM1150 Assembly Instructions Manual

50" 3-in-1 tv stand with integrated mount
Hide thumbs Also See for NT-WGM1150:

Advertisement

Quick Links

Download this manual
Tools needed..................................................................... 4
Parts...................................................................................... 5
Hardware ............................................................................ 6
Assembly instructions.................................................... 8
Finishing the table top assembly .........................13
Finishing the wall-mount assembly ....................22
AS S E MB LY
INSTRUC TIONS
NT-WGM1150
50" 3-in-1 TV Stand with
Integrated Mount

Advertisement

loading
Need help?

Need help?

Do you have a question about the NT-WGM1150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Init NT-WGM1150

Summary of Contents for Init NT-WGM1150

  • Page 1: Table Of Contents

    AS S E MB LY INSTRUC TIONS NT-WGM1150 50" 3-in-1 TV Stand with Integrated Mount Safety information and specifications ..... 2 Tools needed..............4 Parts..................5 Hardware ................6 Assembly instructions............ 8 Finishing the table top assembly ......13 Finishing the swivel mount assembly ....14...

  • Page 2: Safety Information And Specifications

    44.25 × 10.13 × 18.13" (112.39 × 25.73 × 46.05 cm) Keep these items away from young children! Do not lift the glass by the support posts. See instructions for more details. Model #: NT-WGM1150 Distributed by Best Buy Purchasing, LLC Manufacturer: Alart, Inc. Manufacture Date:...
  • Page 3 30"(76.2 cm) 19" (48.26 cm) 50" (127 cm) 19" (48.26 cm) Still need help? Call 800-573-2860...

  • Page 4: Tools Needed

    Tools needed (For optional TV wall mounting) Level Phillips screwdriver Hammer Stud finder Drill Drill bit for 3/8" drill bit Pencil stud wall for concrete wall Still need help? Call 800-573-2860...

  • Page 5: Parts

    Parts Package contents: parts A Stand body (1) B Top frame (1) C Bottom frame (1) D Top shelf frame-wood(1) F Middle shelf-glass (1) E Top shelf-glass(1) G Bottom shelf-glass(1) N Vertical support (1) P Tilt mount (1) R TV bracket (2) Still need help? Call 800-573-2860...

  • Page 6: Hardware

    Hardware Package contents: stand hardware Note: You may receive extra hardware. Make sure you have all the hardware necessary to assemble your new TV stand: Label Hardware Qty. Label Hardware Qty. Small thumbscrew Shelf lock Medium thumbscrew Pivot plug Large thumbscrew TV mount bracket...
  • Page 7 Wall-mount hardware Package contents: wall-mount hardware Note: You may receive extra hardware. Make sure you have all the hardware necessary to assemble your new TV stand: Label Hardware Qty. Label Hardware Qty. M6 × 36 mm Safety bolt (2) bolt M4 ×...

  • Page 8: Assembly Instructions

    Step 1 Assembly instructions Unfold the stand body ( ), then insert the shelf supports ( ) into the side frames. You’ll need: L (2) Still need help? Call 800-573-2860...
  • Page 9 Step 2 Attach the top frame ( ), then secure it into place with two large thumbscrews ( Note: Make sure the front of top frame (B) engages with the side supports on the stand body. You’ll need: J (2) Still need help? Call 800-573-2860...
  • Page 10 Step 3 Attach the bottom frame ( ), then secure it into place with two large thumbscrews ( Note: Make sure the front of bottom frame (C) engages with the side supports on the stand body. You’ll need: J (2) Still need help? Call 800-573-2860...
  • Page 11 Step 4 Attach the top shelf frame ( ) with two small thumbscrews ( • For Table Top and Wall Mount assembly, continue to next step. • For Swivel Stand assembly, continue to page 14. You’ll need: H (2) Still need help? Call 800-573-2860...
  • Page 12 Step 5 Secure the top shelf (E) to the shelf frame (D) with four medium thumbscrews (I), then secure the middle and bottom glass shelves (F and G) with a shelf lock (M). • For final Table Top assembly, continue to the next step. •...

  • Page 13: Finishing The Table Top Assembly

    Finishing the table top assembly Step 1 Optional: Install the anti-tipping hardware. Instructions are included on the bag containing the hardware. You need to remove the one of the top thumbscrews, place the loop on the tipping restraint over the thumbnail screw hole, then replace the thumbscrew.

  • Page 14: Finishing The Swivel Mount Assembly

    Finishing the swivel mount assembly Step 1 Attach the vertical support ( ) by sliding the locking bolts at the bottom of the support into the holes on the stand body, then pressing firmly downward to lock the vertical support into place. Use long thumbscrews (K) to secure the vertical support (N) to the top of the stand frame.
  • Page 15 Step 2 Attach the TV mount brackets ( ) to the back of the TV. Make sure that each TV mount bracket (R) is oriented with the “UP” label on top. If you TV has a flat back, go to page 16. If you TV has a curves back or obstruction, go to page 17.
  • Page 16 Mounting instructions for a TV with a flat back: Select the screws appropriate for your TV and use square washers (M) to attach the brackets to the back of your TV. M5, 6 You’ll need: E (4) F (4) H (4) I (4) M (4) Phillips screwdriver...
  • Page 17 Mounting instructions for a TV with a curved back or obstruction: Select the screws appropriate for your TV. Use square washers (M) and spacers (R) to attach the brackets to the back of your TV. M5, 6 You’ll need: J (4) K (4) L (4) M (4)
  • Page 18 Step 3 Attach the TV mount brackets (R) to the tilt mount (P). Lift the TV up to the tilt mount (P). Warning: Use at least two people to mount the TV onto the tilt mount. Set the hooks on the TV mounting brackets (R) over the tilt mount, then lower the hooks onto the bars of the tilt mount. Still need help? Call 800-573-2860...
  • Page 19 Step 4 Center the TV and let the bottom of the TV rotate downward until it is against the vertical support. Insert the safety bolts (D) to secure the TV in place. You’ll need: D (2) Phillips screwdriver Still need help? Call 800-573-2860...
  • Page 20 Step 5 To adjust the tilt angle, securely hold the top and bottom of the TV, then carefully pull the top of the TV toward you or press it toward the vertical support ( Still need help? Call 800-573-2860...
  • Page 21 Step 6 Optional: Install the anti-tipping hardware. Instructions are included on the bag containing the hardware. You need to remove the one of the top thumbscrews, place the loop on the tipping restraint over the thumbnail screw hole, then replace the thumbscrew. You’ll need: Phillips screwdriver Drill...

  • Page 22: Finishing The Wall-Mount Assembly

    Finishing the wall-mount assembly Step 1A Mount the tilt wall mount to a stud wall (see step 1B for instructions on mounting to a concrete wall). Use a stud sensor to locate two adjacent wall studs, then position the tilt wall mount (P) exactly between the two studs. Use a level to make sure the tilt wall mount is level, then mark the four mounting holes.
  • Page 23 Step 1B Mount the tilt wall mount to a concrete wall. Use a level to make sure the tilt wall mount (P) is level on the wall, then mark the four mounting holes. Drill four 3/8" (10 mm) holes 2" (50mm) deep. Insert four wall anchors (P) into each of the screw holes using a hammer.
  • Page 24 Step 2 Attach the TV mount brackets ( ) to the back of the TV. Make sure that each TV mount bracket (R) is oriented with the “UP” label on top. If your TV has a flat back, go to page 25. If your TV has a curved back or obstruction, go to page 26.
  • Page 25 Mounting instructions for a TV with a flat back: Select the screws appropriate for your TV and use square washers (M) to attach the brackets to the back of your TV. M5, 6 You’ll need: E (4) F (4) H (4) I (4) M (4) Phillips screwdriver...
  • Page 26 Mounting instructions for a TV with a curved back or obstruction: Select the screws appropriate for your TV. Use square washers (M) and spacers (R) to attach the brackets to the back of your TV. M5, 6 You’ll need: J (4) K (4) L (4) M (4)
  • Page 27 Step 3 Lift the TV up to the tilt wall mount (P). Warning: Use at least two people to mount the TV onto the tilt wall mount. Set the hooks on the TV mounting brackets (R) over the tilt wall mount, then lower the hooks onto the bars of the tilt wall mount.
  • Page 28 Step 4 Center the TV and let the bottom of the TV rotate downward until it's against the wall. Insert the safety bolts ( ) to secure the TV in place. You’ll need: D (2) Phillips screwdriver Still need help? Call 800-573-2860...
  • Page 29 Step 5 To adjust the tilt angle, securely hold the top and bottom of the TV, then carefully pull the top of the TV toward you or press it toward the wall. Place the stand with the glass shelves under the TV. Still need help? Call 800-573-2860...
  • Page 30 Step 6 Optional: Install the anti-tipping hardware. Instructions are included on the bag containing the hardware. You need to remove the one of the top thumbscrews, place the loop on the tipping restraint over the thumbnail screw hole, then replace the thumbscrew. You’ll need: Phillips screwdriver Drill...
  • Page 31 For customer service, call: 877-573-2860 (U.S./Canada markets) Still need help? Call 800-573-2860...
  • Page 32 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. © 2011 BBY Solutions, Inc., All Rights Reserved. Init is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
