Summary of Contents for SR Aquaristik DC Series
- Page 1 Water Pump 1000 1500 2000 3000 LIMITED WARRANTY marine fresh w. pond Safe Silent Digital Safety Auto Voltage Operation Control Shut Off User Manual...
- Page 2 User Manual DC Water Pump instructions for use Please note that all SR Aquaristik water pumps can be used internally or externally depending on application. We recommend to use the cage when using the pump submersed/internally to protect the inlet of the pump from debris or obstruction.
-
Page 3: Assembly Guide
User Manual Assembly Guide STEP 1 STEP 2 Connect the power supply to the Connect the pump to the control panel, control panel make sure and line up the indent on the connector STEP 3 Mount the control panel in the desired location using the included screws or Velcro. - Page 4 User Manual STEP 5 Attach the necessary fittings depending on your application STEP 6 Place the pump into the water and then plug in the control panel, never plug the power supply into the control panel last, always plug into the control panel first and then plug in the power supply.
-
Page 5: Setting The Time
User Manual Advanced Control Panel Settings Setting the Time Press the plus and minus button for one second, use the pause button to switch from hours to minutes. Use the plus and minus button to adjust time. Control Panel Codes Press the minus button for three seconds, this will give you the control panel/ pump model number. -
Page 6: What's Inside The Box
User Manual Optional Equipment Float Sensors The optional float sensors can be plugged directly into the advanced Control Panel and used for shutting on or off the pump depending on application. Float sensors are often used in the collection cup of protein skimmers. -
Page 7: Water Pump Specifications
User Manual Water Pump Specifications Water Pump & 500 P U M P C O M PA R I S O N C H A R T 4.65 in 2.87 in FLOW 4.76 in gallons/hour P U M P S P E C I F I C AT I O N S Pump Model: Power Voltage: Amperage:... - Page 8 User Manual Water Pump Specifications Water Pump 1000 P U M P C O M PA R I S O N C H A R T 4.57 in 1000 3.43 in FLOW gallons/hour 5.35 in P U M P S P E C I F I C AT I O N S Pump Model: 1000 Power Voltage:...
- Page 9 User Manual Water Pump Specifications Water Pump 1500 , 2000 & 3000 P U M P C O M PA R I S O N C H A R T 4.76 in 1500 2000 3000 FLOW 3.5 in gallons/hour 6.93 in P U M P S P E C I F I C AT I O N S Pump Model: 1500...
