- Page 1 How to attach your SpiderPro Pad to a ThinkTank ProSpeed Belt Updated 3/1/12 Downloaded from www.spiderholster.com...
-
Page 2: Before You Start
BEFORE YOU START: Please take a look at the images below, as you may have slightly different attachment instructions. A curved Adapter clip? A standard, flat SpiderPro tension clip? Please continue to page 2 below Please skip to page 8 for instructions... - Page 3 Page 2 Thread out the screws that attach the Fabric Pro Pad using the provided 3/32” hex wrench. Use the same wrench to take ProSpeed adapter off the metal ProSpeed Adapter bottom bottom part part. Prepare the two 3/8” Phillips head screws and insert the small washers into them at this time.
- Page 4 Page 3 Align the ProPad holes with the center holes right above the insert. You will be using these two holes to attach the Pad to the Holster. Make sure the ears of the Pad are underneath the belt.
- Page 5 Page 4 Take the bottom part of your ProSpeed adapter and position it under the upper metal clip. Insert the Phillips screw--make sure to thread the washer under the screw head. Carefully wrench one 3/8 PHP screw half way using a Phillips head driver...
- Page 6 Page 5 Wrench the second Screw half way-- keep tightening both screws respectively until they are firmly in. Turn over the belt so that the Pad/ Holster are facing you...
- Page 7 Page 6 Attach your Velcro strip wider part over the Padʼs ear with the long end of the Strip going down as shown. The softer area of the Velcro strip should be facing you. Wrap the Velcro Strip around the belt and to itself--make sure it is as tight as possible!.
- Page 8 Page 7 Repeat the same action on the left side using the second Velcro Strip. The ProPad should not move in any way at this point. You are all done!
- Page 9 Page 8 Take out the screws and washers that attach the SpiderPro clip. Remove the clip. After making sure of the exact location of the Holster on your belt - position your Holster onto the belt, making sure that the holster is aligned in between the beltʼs loop seams.
- Page 10 Page 9 Turn over the belt/holster and press on the belt so you can see the webbing loop Insert the flat clip in between the webbing loop and the belt as shown...
- Page 11 Page 10 Align the Holster Pad upper holes with the holes on the flat clip Screw the Pad in using the washers/screws as shown...
- Page 12 Page 11 Back view - screws/washers inserted. Attach your Velcro strip wider part over the Padʼs ear with the long end of the Strip going down as shown. The softer area of the Velcro strip should be facing you.
- Page 13 Page 12 Wrap the Velcro Strip around the belt and to itself--make sure it is tight. Repeat the same action on the left side using the second Velcro Strip. The ProPad should not move in any way at this point. You are done!
