- Page 1 250kg and 400kg 250kg and 400kg POWER WINCH POWER WINCH Models CHP 250 and CHP 400 Part Nos. 7630400 7630420 PERATING & MAINTENANCE INSTRUCTIONS 0607...
-
Page 2: Safety Precautions
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 3: Electrical Connections
ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING! THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &... -
Page 4: Operation
OPERATION Taking all necessary precautions Fig. 2. previously stated, pay out the cable, under tension so that the coils on the drum remain neatly in place. Attach the hook to the load, ensuring it is directly above the centre of gravity of the load, or in a direct line with the winch. -
Page 5: Troubleshooting
Brake does not operate, 1. Brake is worn out 1. Renew brake and load slips Contact your CLARKE dealer for advice Cable twisted frayed or 1. Incorrectly wound on 1. Replace cable. kinked drum. -
Page 6: Parts List
PARTS LIST CHP250 CHP400 CHP250 CHP400 No.Description Part No. Part No. No. Description Part No. Part No. Fan Cover 502002 502006 Screw 401012 401011 502001 502005 Safety Ring Shield Clamp 510005 510002 Casing w/Stator 634002 634003 U Bolt 510007 510007 Stud 409001 409006... -
Page 7: Parts Diagram
Waste Electrical and Electronic equipment, at a recognised disposal facility. Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.
