RAPIDDOC ™ PoE+ INSTALLATION GUIDE
Base Cover
Wall Mount Base w/ PoE+ Input
Wall Trim Plate
VESA/Wall Mounting Plate
RFID Cards
(included with RFID Reader only)
Hardware
Red Handle Tool
Security
Screw
x4 in Wall Mount Kit
x8 in VESA Mount Kit
