Specification
Model
CA-NBSN52AHD/4
Pick Up Element
AHD/TVI/CVI/CVBS(1/2.7")
Video uncompressed
AHD/TVI/CVI/CVBS/5MP
format
Effective Picture
2688(H)×1944(V)
Elements (H*V)
2560(H)×1953(V)
Real-time resolution
4IN1/5MP
Minimum Illumination
LED 3PCS/20U
OSD Menu
OSD/UTC/CVBS
Video Output
75Ohm BNC*2
Lens
3.6mm/5MP
Auto Electronic Shutter
Manual / Auto: 1/50s ̰ 1 /100,000s
Synchronous System
Internal
White balance
ATW/MSanal/Out door/In door /Awc
NR( noise reduction)
2-DNR/3-DNR/ SMART NR
Digital effect
Freeze, Mirror, D-zoom, Neg. Image
DWDR
High/ Middle/ Low
BLC
BLC/ HLC/ OFF
Lens shading compensation
ON/OFF
Day & Night
Auto/ manual/COLOR/EXT
12V DC(±10%)
Power/Current
AHD transmission range
400 meters, use standard coaxial cable
(RG59) with BNC interface
Led Range
25M IR Distance
Packing List
Dimension
155(W)×145(H)×305(D)
(mm)
Weight (g)
950g
Operating Temperature
-20 ̰ 7 5
℃
CA-NBSN52AHD/4
Series
Color Camera
Day &Night AHD Color Camera
Notes:
Before providing power for the
Camera, please read this User Guide in
Detail!
Do not attempt to disassemble the camera.
If the camera cannot work, please contact
Local franchiser or our company.
Designed by Caddx System Inc.
NEW YORK. USA
www.caddx.us
Advertisement
Summary of Contents for CADDX CA-NBSN52AHD/4 Series
- Page 1 Do not attempt to disassemble the camera. If the camera cannot work, please contact Local franchiser or our company. Packing List Dimension 155(W)×145(H)×305(D) (mm) Weight (g) 950g Designed by Caddx System Inc. NEW YORK. USA Operating Temperature -20 ̰ 7 5 ℃ www.caddx.us...
- Page 2 INTRODUCTION Congratulations on your purchase of this product. * Sensor This User Guide suits CA-NBSN52AHD/4 series product. We adopt the latest CMOS technical of Adopt ½.7”High Resolution AHD sensor. sensor and driver. The most attractive * Auto Gain Control (AGC)
