Black Orchid hydro-box light Assembly & Instruction Manual

Hide thumbs Also See for hydro-box light:

Download this manual

Assembly Instruction Manual

for

70cm x 120cm x 70cm

Need help?

Do you have a question about the hydro-box light and is the answer not in the manual?

Page 1 Assembly Instruction Manual 70cm x 120cm x 70cm...
Page 2 Box Contents Pole 120cm Pole 70cm Pole 70cm Pole 120cm Pole 70cm Tent Fabric Splash tray fabric Frame Corner joints (inc 1 spare)
Page 3 Please follow the instructions carefully Tent Assembly Instructions STEP Create the Base of the frame using 4 corner joints, 2 A poles and 2 B poles...
Page 4 Tent Assembly Instructions Push the poles into the corner joints until the locking ball pops back out into the hole STEP...
Page 5 Tent Assembly Instructions Join the base together STEP Create the top as you did the base...
Page 6 Tent Assembly Instructions STEP Add poles C to the bottom...
Page 7 Tent Assembly Instructions STEP Join together the base of the frame with the top of the frame.
Page 8 Add poles D and E to the top of the frame Tent Assembly Instructions STEP...
Page 9 Tent Assembly Instructions STEP Unfold your tent and place the frame into the base...
Page 10 Tent Assembly Instructions STEP Make sure the bottom of tent is fitted firmly around the frame before lifting the top of the tent onto the frame...
Page 11 Tent Assembly Instructions STEP Lift the back of the tent up and fit it around the top of the frame. Next zip the back up and over the top to the front, sealing the tent up.
Page 12 Tent Assembly Instructions STEP Add the splash tray in the bottom once complete...
