Summary of Contents for Schertler CHARLIE
- Page 1 CHARLIE Jazz Guitar amplifier...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT ENCLOSURE THAT MAY BE OF A SUFFICIENT MAGNITUDE TO CONSITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE PRODUCT.
- Page 3 “muddy” with compressed harmonics. In contrast, CHARLIE is designed to offer maximum intelligibility in that range. Equipped with a Class A preamp, an uncompromising speaker/power amp combination and traditional spring reverb, CHARLIE delivers a warm, clear sound that gives the jazz guitar its true voice in any ensemble.
- Page 4 Matches the impedence from 22Kohm to 2Mohm (adjustable) 1.3. 10V Phantom power supply with 10V for powering electret microphones and Schertler STAT, Basik and Lydia series. 1.4. GAIN This variable gain preamplifier adjusts the sensitivity level to ensure the best possible processing of the signal through the channel.
- Page 5 2. BACK 2.3. 2.2. 2.1. 2.1. MAIN POWER CONNECTION Connection to mains (230V AC/120V AC 50Hz/60Hz) PLEASE ENSURE THE PROPER VOLTAGE AND USE THE ORIGINAL CONNECTION CABLE! 2.2. NET SWITCH This switch changes the main power voltage from 230V AC to 120V AC 2.3.
- Page 6 3. BLOCK DIAGRAM...
- Page 7 WARNINGS PRECAUTIONS Read carefully this manual and follow these WARNING precautions before operating the device Keep this manual for possible future needs Pay attention not to pour liquids onto the device and do not operate in conditions of excessive humidity Do not install the device close to sources of excessive heat, do not expose it to direct solar radiation and do not position it without protection in a dusty environment Be sure that the mains voltage does not exceed the value indicated on the back panel...
- Page 8 AND THUS, MISUSE OF OUR PRODUCTS ARE NOT COVERED UNDER RIGHTS OBTAINED THROUGH OUR WARRANTY POLICY OR THAT OF INTERNA- TIONALLY RECOGNIZED TERMS AND CONDITIONS. SCHERTLER SA IS CONSTANTLY AIMING TO IMPROVE ITS RANGE OF PRODUCTS THEREFORE, SCHERTLER SA RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATIONS WITHOUT NOTICE.
