Ice PORTABLE FRIDGE Series Instruction Manual

Refer to the table for panel type and model
A
MINI SERIES 15L / 20L / 30L
B
ELITE S SERIES 40L / 50L
C
NOT SUPPORTED
D
ELITE T SERIES 36L / 50L / 60L
E
ELITE S SERIES 75L / 100L
Manual Revision: 2019-02A
All contents in this manual are copyrighted under IceCube
Statement!
Coolers LLC Wilmington DE ZIP 19899 U.S. Do not make copies or
distributing any copyright materials without seeking consent of the
rightful owner.
www.icecubecoolers.com, All Rights Reserved IceCube Coolers LLC.

Safety Instructions

• The installation of DC power source in the boat must be handled by qualified
electricians if applicable.
• Ensure connecting t h e power to the suitable voltage socket.
• Before switching on the fridge, ensure the fridge has sit in the upright position
for at least 3 hours.
• Always keeping the fridge in upright position during operation. The tilt angle must
be less than 5° and not exceeding 45° for a short period of time.
• Good ventilation: the fridge must be well ventilated for heat dissipation and
maintain some space around the unit.
(Near the vents leave Back Space ≥ 200mm, Side Space≥100mm)
• Avoid heat source: the fridge should be placed somewhere well-ventilated and
away from heat source, avoid direct sunlight.
• Keep it stable: Do not turn the fridge upside down for
to rain or operate near water.

Troubleshooting

The fridge is not working:
• Check if power supply has malfunctioned or not.
• Check whether the plug or socket is loose.
• Check if the fuse has blown.
• Check if the switch is on or not.
• Compressor may have entered protection mode by delaying startup for 3mins.
Food is frozen:
• The temperature is set too low.
Water flowing sound is inside the fridge:
• It is the flowing sound of refrigerant which is normal.
There are water droplets around the fridge casing or lid
• When moisture in the air meets the lower temperature inside the fridge, it will
naturally cause condensation to form moisture. This is a
The compressor is slightly noisy when starting:
• The noise will be less audible when the compressor stabilizes the cooling
throughout its operation.
Code F1 displayed:
• This is the protection mode to shut off the unit due to low battery voltage. This
can be solved by setting battery protection from H to M or from M to L
Code F2 displayed:
• This is the protection mode to shut off the unit due to fan overload. Please turn
the unit off and restart it after 30mins.
Code F3 displayed:
• This is the protection mode to shut off the unit due to excessive running load of
compressor. Please turn the unit off and restart it after 30
Code F4 displayed:
• This indicates the compressor is overloaded or working at a too low speed. Please
turn the unit off and restart it after 30mins.
Code F5 displayed:
• This indicates the compressor has overheated. Move the fridge to a well-
ventilated area an d restart it after 30mins.
Code F6 displayed:
• This indicates unknown parameters were detected by the controller. Please restart
the unit.
Code F7 or F8 displayed:
• This indicates error in reading from temperature sensor. Please check the
sensor terminals.
If the code persists, please contact IceCube Support on
help@icecubecoolers.com
drainage. Do not expose it
gap:
normal.
ENGLISH INSTRUCTIONS MANUAL
minutes.
Please read this operating manual carefully before operating the unit.
Operating Manual
PORTABLE FRIDGE SERIES
Mobile APP Control by Bluetooth
I O S & A n d r o i d
Keep manual in a safe place for future reference.
