TSYS LAN based Card Processing Terminal Setup with DolphinPOS
How to connect to TSYS PAX-S300 Card Processing Terminal
via Physical Ethernet LAN and its setup?
Contact information:
Index
PAX Card Processing Terminal Setup
Link with DolphinPOS APP
Enable Static IP to PAX Terminal
DolphinPOS User Guide
(TSYS, Model PAX-S300)
May-21-2020, Version V1.0
support@dolphinpos.com
Page#
2-7
7-9
9-11
Page 1
Advertisement
Related Manuals for TSYS PAX-S300
Summary of Contents for TSYS PAX-S300
- Page 1 TSYS LAN based Card Processing Terminal Setup with DolphinPOS How to connect to TSYS PAX-S300 Card Processing Terminal via Physical Ethernet LAN and its setup? (TSYS, Model PAX-S300) May-21-2020, Version V1.0 Contact information: support@dolphinpos.com Index Page# PAX Card Processing Terminal Setup...
- Page 2 TSYS LAN based Card Processing Terminal Setup with DolphinPOS PAX Card Processing Terminal Setup DolphinPOS User Guide Page 2...
- Page 3 TSYS LAN based Card Processing Terminal Setup with DolphinPOS Step 1: Connect the Ethernet LAN cable into “red cord” as shown in below. Step 2: Connect the Power Pin of the cable into the hole has shown in below and other end of it goes into power supply.
- Page 4 TSYS LAN based Card Processing Terminal Setup with DolphinPOS Note: Make sure both PAX terminal device and IPAD which you are using for POS APP are on the same LAN network. Step 3: On the PAX front Panel a) Hold “F+1” keys together b) default Password is today’s date mmddyyyy (example march 13th 2020 i.e...
- Page 5 TSYS LAN based Card Processing Terminal Setup with DolphinPOS d) Enter your password again (it’s today’s date mmddyyyy, if it is not changed) e) Scroll down 2 pages (press down arrow two times) and press "1. LAN Parameters". f) press “2.IP Address” and Note down the IP Address (xxx.xxx.xxx.xxx)
- Page 6 TSYS LAN based Card Processing Terminal Setup with DolphinPOS g) press enter h) press down arrow & go to “ping” option and press “green” enter button If DNS resolve error appears (your internet may be down please confirm) If ping is ok, click red ‘x’ button, and press red ‘x’ button 3 times to go...
- Page 7 TSYS LAN based Card Processing Terminal Setup with DolphinPOS To verify the internet connectivity of PAX LAN setup, you can do same ping test from DOS command prompt with below command on the PC (which should be on the same local network) C:\xxx>ping xxx.xxx.xxx.xxx –t (Where xxx.xxx.xxx.xxx is your PAX LAN IP address...
- Page 8 TSYS LAN based Card Processing Terminal Setup with DolphinPOS Example in PAX S300 if IP address is 192.168.001.155 , then in IPAD APP it should be 192.168.1.155 4) Port No.: 10009 5) Then Tap on “Configure Pin Pad” DolphinPOS User Guide...
- Page 9 TSYS LAN based Card Processing Terminal Setup with DolphinPOS 6) Go to “General” and Select card provider to “TSYS” from the dropdown 7) In the same page “Enable Capture Signature” flag if you want to capture signature on the TSYS display.
- Page 10 TSYS LAN based Card Processing Terminal Setup with DolphinPOS 8) That’s it, just close the application and open it. You are good to go! How to make IP address to Static 1. Press Menu or "FUNC" and "1" at the same time 2.
- Page 11 TSYS LAN based Card Processing Terminal Setup with DolphinPOS 8. Go back into “LAN Type” and verify that LAN Type:”2” is selected before proceeding. 9. Go back to the home screen by using the back button on the screen several times.
