- Page 1 SKU# 035-0176-0 (RSI305833G) 2K QHD DASHBOARD CAMERA G-SERIES Installation and Care! Please read this manual carefully before using Owner’s Manual and keep it for future reference.
-
Page 2: Table Of Contents
Contents of the Manual Introduction Package Contents Features Safety Precautions Getting Started Recording Screen Function Buttons in Different Modes Loop Recording Screenshot Emergency Recording FCWS (Forward Collision Warning System) LDWS (Lane Departure Warning System) Browse and Playback Videos Settings Reset the Device Transfer Files to A Computer Trouble Shooting Specifications... -
Page 3: Introduction
Introduction Thank you for purchasing RELOAD dash camera which captures real time video of events happening outside your vehicle while driving. Mounted on your car's windshield, the camera records video in 2K 1440P & Full HD 1080P to ensure all the moments of your trip are recorded. -
Page 4: Safety Precautions
Safety Precautions These usage and safety guidelines are IMPORTANT! Please follow them carefully to ensure your own personal safety and help protect your dash camera from potential damage. General Use • For in-car use only. • It's dangerous to operate the dash camera while driving. Please always operate the camera when the car stops. -
Page 5: Getting Started
Getting Started 1. Know your dash camera Reset Button USB connector (for power supply and connecting with PC) AV Output MicroSD Card Slot Speaker Function Button USB Connector (for power Bracket Socket supply only) GPS Recevier & Mounting Base Camera Lens 2. - Page 6 Getting Started 6) Connect the device with car 12V socket with the Fig. D provided car adaptor. 7) Please organize your car adaptor cables so that the cable is not hanging around (Fig. D). Note: 1) Make sure the camera is in the middle of the windshield so that FCWS and LDWS can work properly.
- Page 7 Getting Started 5. You will be asked to set the language, date, time and format the MicroSD memory card. 5.1 Please use to set the language, date and time. & are used for select values and is used to confirm your choice. 5.2 If you use the provided memory card for the first time, the camera will remind you to format the card.
-
Page 8: Recording Screen
Recording Screen Recording Icon FCWS (when activated) Recording Status Indicator Recording Time (flashing red light means Center of View recording) Recording Resolution Emergency Recording Date Stamp Indicator (when activated) Time Stamp Microphone Status Indicator Memory Card LDWS ( when activated) Function Buttons in Different Modes Mode Video Recording... -
Page 9: Loop Recording
Loop Recording With Loop Recording enabled (by default), the oldest files in the memory card will be overwritten by new video files when memory card capacity is full. To disable Loop Recording, please enter setting menu to operate. Screenshot Press to capture the images while recording. -
Page 10: Fcws (Forward Collision Warning System)
FCWS (Forward Collision Warning System) This function will be activated when driving speed is over 50km/h. The camera will detect the distance to front car and give warning sound and screen warning to the driver to keep the safe distance if the car is too close to the front car. LDWS (Lane Departure Warning System) This function will be activated when driving speed is over 50km/h, the camera will detect your car position and the two lanes beside your cars. -
Page 11: Browse And Playback Videos
Browse and Playback Videos 1. Playing Videos / Photos 1) During video recording, press stop recording and then press to enter "playback" interface. 2) Use to select desired files and press button to review the video or photo. 3) Press to fast reverse. -
Page 12: Settings
Settings In the Settings menu, you can adjust settings such as video resolution, recording time, and G-Sensor sensitivity. You can also set the date/time, change interface language, format memory card etc.. 1. During video recording, first press to stop recording and then press button to enter the setting interface. - Page 13 Settings LDWS: Lane Departure Warning System. Available options: On / Off FCWS: Forward Collision Warning System. Available options: On / Off Date Stamp. Available options: On / Off Record Audio: Turn On / Off the microphone during video recording. Available options: On / Off Screen Saver: Set the time to turn Off the screen.
-
Page 14: Reset The Device
Settings Format: Format the MicroSD memory card. Available options: Cancel / OK Format Warning: Remind the user to format the memory card after a period of time. Available options: 15 Days / 30 Days / 60 Days / Off Default Setting: Return menu setting to defaults. Available options: Cancel / OK Version: Shows firmware version. -
Page 15: Transfer Files To A Computer
Transfer Files to A Computer To transfer files between the dash camera memory card and your computer: Option 1: Take the MicroSD memory card out of the camera and use a compatible card reader to transfer files to your computer. Option 2: Connect the camera with computer with the provided USB cable, and you will see a new storage device in your laptop. -
Page 16: Trouble Shooting
Trouble Shooting If a problem occurs with your dash camera, please first check the information listed below. If you are unable to solve the problem with the trouble shooting information, please contact 1 877 466 8191 for help. The camera can't be powered on Check the followings: 1. -
Page 17: Specifications
Specifications Processor NTK96660 Build-in Image Sensor OV4689 4MP Sensor Angel of View 140° Diagonal FHD 2560 x 1440 @ 30fps Shooting Resolution Rate FHD 1920 x 1080 @ 60fps FHD 1920 x 1080 @ 30fps 30FPS @ 1440P; 60FPS @ FHD1080P; Frame Rate 30FPS @ FHD1080P Video Compression Format... -
Page 18: Warranty
Warranty Always keep your receipt as proof of purchase! We're here to help! You are covered with one year manufacturer's warranty against defects in workmanship and materials. If you have any questions or comments call our toll-free hotline: 1 877 466 8191 for help.
