Page 2
Portable TV Stand S p e c i f i c a t i o n *Loading Capacity:60~90kgs LCD TV *TV Height adjustment (up-down movement) range:500mm *Meet VESA: X:30~1040; Y:50~900 1080 Unit:mm P a r t s L i s t MAIN PARTS ITEM PARTS...
Page 3
Portable TV Stand I n s t a l l a t i o n Top bar MM-0011/A340-NB Page 2...
Page 4
Portable TV Stand I n s t a l l a t i o n III. Height Adjustment Install the wall mount in the mobile stand MM-0011/A340-NB Page 3...
Page 5
Portable TV Stand I n s t a l l a t i o n VII. Screw selected M6X10 M6X15 M8X10 M8X15 VIII. Lock the screw after you hang the TV on. MM-0011/A340-NB Page 4...
Page 6
Portable TV Stand I n s t a l l a t i o n Make sure the TV is balanced. Set the balance, adjust the two springs equally until balanced. Weight Loading + Weight Loading - Do not remove the screw covers or adjust the screws W a r n i n g For safety reasons a minimum of 2 people are required to install.
